- Page 1 M-29-FW Network Bullet Cameras Quick Guide V1.00...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! • Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
-
Page 3: Packing List
DC interface Plug 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION! • The cable connector must not be exposed and must be kept away from water. • Restore and fasten the device after dismounting. •... -
Page 4: Mount Your Camera
abnormally. If it is required to lengthen the power cable, lengthen the cable between the power adapter and the mains. Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. - Page 5 in the wall. (2) Lead the cables across the hole on the wall. 2. Drill holes on the wall. (1) Use a Ø6-6.5mm drill bit. (2) Drill 30 mm-depth guide holes according to the positions marked by sticker. 3. Mount the plastic rivets of self-tapping screws. Knock the plastic rivets into the guide holes and ensure that they are tightened up.
-
Page 6: Access Your Camera
6. Adjust the monitoring direction. (1) Adjust the opening of the universal joints as required. (2) Rotate the spherical hinge of the camera to get the desired monitoring direction. (3) Tighten the locknut. NOTE! The preceding installation process is for concealed installation, during which holes are punched on the wall and cables are penetrated into the wall. - Page 7 NOTE!： • DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in. • You may need to install a plug-in at your first login. Please follow the on-screen instructions to complete the installation and then open the browser again to log in.
- Page 8 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
- Page 9 whether in contract, strict liability or tort (including negligence or otherwise) in any way out of the use of the product, even if our company has been advised of the possibility of such damages (other than as may be required by applicable law in cases involving personal injury, incidental or subsidiary damage).
- Page 10 Make sure the device is securely installed or placed on a flat surface to prevent falling. Unless otherwise specified, do not stack devices. Ensure good ventilation in the operating environment. Do not cover the vents on the device. Allow adequate space for ventilation.
- Page 11 2013/56/EC. For proper recycling, return the battery to your supplier or to a designated collection point. © i-PRO Co., Ltd. All Rights Reserved. i-PRO, Viewnetcam.com, advidia, VideoInsight, CloUDE, and Unified Digital Evidence are registered trademarks or trademarks of i-PRO Co., Ltd. or i-PRO Americas Inc.
