- Page 1 M-49-V-V2 Varifocal Bullet Network Camera Quick Guide V2.00...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! • Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
-
Page 3: Packing List
4. If your camera has a DC cable and you will not use it, insert the plug into the interface. DC interface Plug 5. (Optional) After the waterproof treatment is completed, put the cables into a waterproof junction box (purchased separately). CAUTION! •... -
Page 4: Maintenance
Precautions Use a power adapter or a PoE device that meets requirements. Otherwise, the device may be damaged. Make sure the length of the power cable between the power adapter and the camera is not too long, otherwise the voltage of the camera is lowered, causing the camera to work abnormally. -
Page 5: Cable Connection
Cable Connection The tail cable may vary with device model. The figure below is for illustrative purposes only. DC12V IN Ethernet interface Power interface Alarm input / Alarm output Audio input/Audio output Mount Your Camera (Optional) Insert the Micro SD Card For cameras that support Micro SD, you need to insert the Micro SD card after opening the bottom cover of camera. - Page 6 1. Locate the positions of the holes, drill holes 2. Loosen the hex fillister-head screw using a on the wall, mount the plastic rivets of self- 4# hex L-key to avoid damaging the tapping screws. universal joint. 3. Mount your camera onto the wall and 4.
-
Page 7: Access Your Camera
Access Your Camera Before you begin, check that: Your camera is operating properly and connected to the network. Follow these steps to access your camera through the Web: 1. Open your browser, input the IP address of your camera in the address bar and then press Enter to open the login page. - Page 8 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
- Page 9 interruption, loss of business information, or any special, direct, indirect, incidental, consequential, pecuniary, coverage, exemplary, subsidiary losses, however caused and on any theory of liability, whether in contract, strict liability or tort (including negligence or otherwise) in any way out of the use of the product, even if our company has been advised of the possibility of such damages (other than as may be required by applicable law in cases involving personal injury, incidental or subsidiary damage).
- Page 10 Store or use the device in a proper environment that meets environmental requirements, including and not limited to, temperature, humidity, dust, corrosive gases, electromagnetic radiation, etc. Make sure the device is securely installed or placed on a flat surface to prevent falling. ...
- Page 11 Regulatory Compliance FCC Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
