Adaptive Streams ............................. 20 Image Adjustment ............................20 Setting scene ..............................20 Image Enhancement ............................ 22 Exposure ..............................24 Smart Illumination ............................27 Focus (Applicable in M-400-P only) ......................28 White balance .............................. 29 Advanced ..............................30 Lighting type ..............................30 https://i-pro.com/global/en/surveillance/advidia...
Page 3
ARP Protection ............................. 59 IP Address Filtering ............................59 Access Policy ..............................60 Watermark ..............................60 System ................................61 Time ................................61 Synchronizing with the NTP Server ......................61 Setting the DST ............................61 Server (Applicable in M-400-P only) ......................62 https://i-pro.com/global/en/surveillance/advidia...
Page 4
Make a patrol plan........................... 83 Start a patrol route ..........................84 Edit a patrol route ........................... 84 Delete a patrol route ..........................85 PTZ ................................. 85 Setting Home Position ..........................85 Remote Control PTZ ............................. 85 PTZ Limit............................... 86 Resume Patrol .............................. 87 https://i-pro.com/global/en/surveillance/advidia...
Symbols The symbols in the following table may be found in this manual. Carefully follow the instructions indicated by the symbols to avoid hazardous situations and use the product properly. https://i-pro.com/global/en/surveillance/advidia...
After the camera is started, you can access the camera from a PC client installed with a web browser or the client software Advidia Guard. Internet Explorer (IE) is a recommended web browser. For more information about Advidia Guard, refer to the Advidia Guard User Manual.
Before you access the camera, follow the steps to set User Account Control Settings to Never notify. Logging In to the Web Interface The default static IP address of the camera is 192.168.1.13, and the default subnet mask is 255.255.255.0. https://i-pro.com/global/en/surveillance/advidia...
Page 8
DHCP is turned on by default. If a DHCP server is used in the network, the IP address of your camera may be assigned dynamically, and you need to use the correct IP address to log in. Use the Advidia Guard client to view the dynamic IP address of your camera.
Set the server for storing photos based on the actual photos. networking. Set the information displayed on the screen as needed, for Set OSD. example, time. Change the default password and add common users as (Optional) Manage users. needed. https://i-pro.com/global/en/surveillance/advidia...
The local parameters may vary with models. Please see the actual Web interface for details. 1. Select Setup>Common>Local Parameters Fig. 1 for M-49-FW Fig 2 for M-400-P 2. Modify the settings as required. The following table describes some major parameters.
260 bytes. If the limit is exceeded, recording or snapshot during live view will fail, and messages will appear on the screen. 3. Click Save Network Configuration Ethernet Modify communication settings such as the IP address for the camera so that the camera can communicate with other devices. https://i-pro.com/global/en/surveillance/advidia...
This function is not supported by some models. Please see the actual model for details. If the camera is connected to the network through Point to Point over Ethernet (PPPoE), you need to select PPPoE as the IP obtainment mode. https://i-pro.com/global/en/surveillance/advidia...
The Dynamic Host Configuration Protocol (DHCP) is enabled by default when the camera is delivered. If a DHCP server is deployed in the network, the camera can automatically obtain an IP address from the DHCP server. To manually configure DHCP, follow the steps below: 1. Click Setup>Network>Network https://i-pro.com/global/en/surveillance/advidia...
All snapshots (except face detection) are saved through the general FTP service. After the configuration of FTP, you will be able to upload snapshots from network cameras to the specified FTP server. General 1. Click Setup>Storage>FTP. Go to General tab. https://i-pro.com/global/en/surveillance/advidia...
This function is used to store snapshots taken for smart functions such as face recognition. To use smart FTP, click Setup > System > Server > Intelligent Server and set Platform Communication Type to FTP. Click Setup>Storage>FTP. Go to Smart tab. https://i-pro.com/global/en/surveillance/advidia...
When enabled, the e-mail will contain 3 instant snapshots as attachment according to the Capture Interval. Username/Password Username and password of the registration email address. The password allows the following special characters \ / : * ? ’ ” <> | % & Click Save. https://i-pro.com/global/en/surveillance/advidia...
Status will show Inactive. 3. Click Save. 1. Click Setup>Network>DNS 2. Set DNS server addresses. 3. Click Save DDNS NOTE! This function is not supported by some models. Please see the actual model for details. 1. Click Setup>Network>DDNS. https://i-pro.com/global/en/surveillance/advidia...
If you change the Read-Only Community Name, you should change it into the same one on the central server, or the two-way authentication will not be completed. 802.1x 802.1x provides authentication to devices (e.g., cameras) trying to connect to a network. Only the authenticated devices can connect the network. This enhances security. 1. Click Setup>Network>802.1x. https://i-pro.com/global/en/surveillance/advidia...
60, alarm report and configuration management is set to 0, and FTP is set to 4, when network congestion occurs, the priority is to ensure the smooth running of audio and video. 3. Click Save. Note: To use QoS, make sure that the switch support QoS mode. https://i-pro.com/global/en/surveillance/advidia...
The scene management page of some models is displayed as follows; you can take the following steps to configure the scene. Click Scenes. Select a scene, and then set scene switching parameters. The following table describes some major parameters. https://i-pro.com/global/en/surveillance/advidia...
Page 21
Scene Name Name of the current scene. The device provides several preset scene modes. When you select a scene, the corresponding image parameters are displayed. You can adjust image settings according to actual needs. For M-49-FW: Starlight Common ...
If multiple non-default scenes are triggered, then the device will switch to the scene with the minimum number (starts from 1 to 5). Image Enhancement NOTE! This function may vary with models. Please see actual Web interface for details. 1. Click Setup>Image>Image and then click Image Enhancement. https://i-pro.com/global/en/surveillance/advidia...
Page 23
Set the degree of difference between the blackest pixel and the whitest pixel. Low contrast High contrast Sharpness Contrast of boundaries of objects in an image. Low sharpness High sharpness Reduce the noise of images. The function may cause image blurring. Noise Reduction https://i-pro.com/global/en/surveillance/advidia...
90°Anti-clockwise 3. To restore default settings in this area, click Default. Exposure NOTE! This function may vary with models. Please see actual Web interface for details. The default settings are scene adaptive. Use default settings unless modification is necessary. https://i-pro.com/global/en/surveillance/advidia...
Page 25
2. Set the parameters as required. The following table describes some major parameters. Parameter Description Exposure Mode Select the correct exposure mode to achieve the desired exposure effect. Automatic: The camera automatically adjusts exposure according to the environment. Custom: The user sets exposure as needed. https://i-pro.com/global/en/surveillance/advidia...
Page 26
Mode In this mode, the camera can switch between night mode and day mode automatically. Night: The camera provides high-quality black and white images using the existing light Day: The camera provides high-quality colour images using the existing light. https://i-pro.com/global/en/surveillance/advidia...
This function may vary with models. Please see actual Web interface for details. 1. Click Setup>Image>Image and then click Smart Illumination 2. Select the correct IR control mode and set the parameters. The following table describes some major parameters. https://i-pro.com/global/en/surveillance/advidia...
You can set this parameter only when Control Mode is set to Manual. 3. To restore the default settings, click Default Focus (Applicable in M-400-P only) NOTE! This function may vary with models. Please see actual models for details. Click Setup>Image>Image and then click Focus. https://i-pro.com/global/en/surveillance/advidia...
Sodium Lamp: The camera adjusts red and blue offset automatically according to the light condition (the colour tends to be red). Red Offset Adjust the red offset manually. Note: You can set this parameter only when White Balance is set to Fine Tune. https://i-pro.com/global/en/surveillance/advidia...
2. Enable the defog function and then select a level for the scene. Level 9 achieves the maximum defog effects, and level 1 achieves the minimum. Defog Off Defog On 3. To restore the default settings, click Default Lighting type https://i-pro.com/global/en/surveillance/advidia...
To set the position precisely, use the X and Y coordinates under Overlay Area. Overlay OSD Content: The drop-down list provides Time, Pre-set and Serial Info. You may also select Custom and enter the content you want. https://i-pro.com/global/en/surveillance/advidia...
Some models support up to 24 privacy masks. The same picture shows up to only 8 privacy masks. 2MP cameras only support up to 4 privacy masks. 1. Click Setup>Image>Privacy Mask. 2. Click to add a privacy mask, and click to delete a mask https://i-pro.com/global/en/surveillance/advidia...
Web interface. After enabling the sub or third stream, modify the parameters as required. The parameters for the sub and third stream have the same meanings as that for the mainstream. 1. Click Setup>Video & Audio>Video https://i-pro.com/global/en/surveillance/advidia...
Page 34
Smooth increases the level of smoothing but will affect image quality. Note: In a poor network environment, you can enable smoothing to get more fluent video. BNC Output BNC output supports NTSC and PAL. (Only application for M-400-P) 3. Click Save https://i-pro.com/global/en/surveillance/advidia...
This function is not supported by some models. Please see the actual model for details. Click Setup>Video & Audio>Audio. Fig 1 for M-400-P Fig 2 for M-49-FW Modify the settings as required. The following table describes some major parameters. https://i-pro.com/global/en/surveillance/advidia...
Only PCM audio files are allowed, and the max size of a PCM file is 100K. Click Save Snapshot Click Setup>Video & Audio>Snapshot Select On, and then set resolution, most large and schedule as needed. Some parameters are described in the table below. https://i-pro.com/global/en/surveillance/advidia...
When Region of Interest (ROI) is enabled, the system ensures image quality for ROI first if the bit rate is insufficient. NOTE! This function is not supported by some models. Please see the actual model for details. 2MP camera model supports up to 8 ROI areas. 1. Click Setup>Video>ROI Fig 1 for M-400-P https://i-pro.com/global/en/surveillance/advidia...
Fig 2 for M-49-FW 2. Click , and then drag the mouse to cover the intended part of the images. To delete, select the area and then click Media Stream configuration Media Stream You can display the established media streams from a camera. You may also set the camera, so it transmits code streams by the UDP or TCP protocol to a specified IP address and port number.
2. Set the multicast address (224.0.0.0to239.255.255.255) and port number (0 to65535). 3. Click Save. Intelligent Alarm Configuration You can configure intelligent monitoring to count people and monitor moving objects. Intelligent monitoring includes people counting, intrusion detection, and auto tracking. The supported functions may vary with camera model. https://i-pro.com/global/en/surveillance/advidia...
The supported alarm triggering, and arming schedule may vary with camera model. Please see the actual Web interface for details. The camera takes the snapshot and sends the snapshot to the back end. 1. Click Setup >Intelligent>Smart. Choose Cross Line and then click. https://i-pro.com/global/en/surveillance/advidia...
Fig 1 for M-49-FW Fig 2 for M-400-P 1. Select Cross Line Detection. 2. In the Detection Rule area, click to add a new detection area. To delete a detection area, click 3. On the small preview window, drag the line to the intended position and set the detection range.
The supported alarm triggering, and arming schedule may vary with camera model. Please see the actual Web interface for details. The camera takes the snapshot and sends the snapshot to the back end. 1. Click Setup > Intelligent > Smart. Choose Leave Area, and then click https://i-pro.com/global/en/surveillance/advidia...
The supported alarm triggering, and arming schedule may vary with camera model. Please see the actual Web interface for details. The camera takes the snapshot and sends the snapshot to the back end. 1. Click Setup >Intelligent>Smart. Choose Intrusion and then click https://i-pro.com/global/en/surveillance/advidia...
Web interface for details. The camera takes the snapshot and sends the snapshot to the back end, which will compare the data with that in the database. Click Setup > Intelligent > Smart. Choose Face, and then click https://i-pro.com/global/en/surveillance/advidia...
Page 45
You can set the number of photos to select. Selection Mode Speed Priority: The camera selects the optimal snapshots from the moment that the face is detected till Selection Timeout is up. You can set the number of photos to select. https://i-pro.com/global/en/surveillance/advidia...
5. Set Max. Size and Min. Size under Filter by Object Size. Only objects within the size range will be counted; others will be filtered and not counted. The maximum width or height must be greater than the minimum width or height. https://i-pro.com/global/en/surveillance/advidia...
This function is not supported by some models. Please see the actual model for details. The alarm triggered actions may vary with models. Please see the actual Web interface for details Area Detection 1. Click Setup > Events >Common Alarm >Motion Detection. Set Detection Mode to Area. https://i-pro.com/global/en/surveillance/advidia...
Page 49
If the same alarm is not triggered within the set time, the alarm will be cleared, and the same alarm can be reported again. If the same alarm is triggered within the set time, the alarm will not be cleared until the suppress alarm time expires. Then the same alarm can be reported again https://i-pro.com/global/en/surveillance/advidia...
NOTE! This function is not supported by some models. Please see the actual model for details. The alarm triggered actions may vary with models. Please see the actual Web interface for details. 1. Click Setup>Events>Common Alarm >Tampering Alarm. https://i-pro.com/global/en/surveillance/advidia...
NOTE! This function is not supported by some models. Please see the actual web interface for details. The alarm triggered actions may vary with models. Please see the actual Web interface for details. 1. Click Setup>Events>Common Alarm >Audio Detection. https://i-pro.com/global/en/surveillance/advidia...
Page 52
Audio detection results are shown in real time. The red part indicates the reported audio detection alarms. Volume Scale Difference Set the alarm-triggered actions and arming schedule as required. For the detailed steps, see the descriptions of alarm-triggered actions in Configuring Motion Detection Alarm. https://i-pro.com/global/en/surveillance/advidia...
Normally Open or Normally Closed. The alarm output duration is configurable. NOTE! This function is not supported by some models. Please see the actual model for details. 1. Click Setup>Events>Common Alarm >Alarm Output https://i-pro.com/global/en/surveillance/advidia...
Post-Record is displayed if the camera is capable of this feature; This parameter is not displayed if not supported by the camera Setting Edge Storage Edge storage is used to save video data and snapshots to the memory card directly. Edge storage is recommended when the camera is running in stand-alone mode. https://i-pro.com/global/en/surveillance/advidia...
To format the memory card, disable the storage function for the card first. Then Click Format and then click OK to confirm the operation. The system will restart when the format is completed. Information about the total and free space is displayed. https://i-pro.com/global/en/surveillance/advidia...
A camera under centralized management can use the memory card as a backup storage resource of the central management server. If storage from the camera to the central storage device is interrupted due to unstable network connection, the camera automatically will start cache post recording and store videos to the memory card. https://i-pro.com/global/en/surveillance/advidia...
(if camera has SD card). Up to 32common users are allowed in the system. You can add a user on the user management interface (under Setup>Security> User). After the user is added successfully, you can change the password by entering the new password or delete the user by clearing the username. https://i-pro.com/global/en/surveillance/advidia...
RTSP (Real Time Streaming Protocol) is an application layer protocol. To transmit and control the audio and video, set RTSP authentication on the Web interface 1. Click Setup>Security> Network Security>Authentication. 2. Select an authentication mode and then click Save. https://i-pro.com/global/en/surveillance/advidia...
2. Select the check box to enable the ARP binding function and set the gateway MAC address. 3. Click Save. IP Address Filtering Use IP address filtering to allow or forbid access from specified IP address(es). NOTE! This function is not supported by some models. Please see the actual model for details. https://i-pro.com/global/en/surveillance/advidia...
2. Select On to enable Illegal Login Lock and MAC Authentication. 3. Click Save. Watermark Use watermark to encrypt custom information with video to prevent unauthorized delete or alteration. NOTE! Only some camera models support this function. 1. Click Setup>Security>Watermark. https://i-pro.com/global/en/surveillance/advidia...
2. Set Sync Mode to Sync with NTP Server, and then set the IP address and port of the NTP server and update interval. 3. Click Save. The camera will periodically synchronize time with the NTP server. Setting the DST 1. Click Setup>Common>Time, and then click the DST tab. https://i-pro.com/global/en/surveillance/advidia...
Pixel mode coordinate X/Y= (Percentage mode coordinates*image width/height)/10000. 3. Select Enable Intelligent Server 2, and complete the settings, then the snapshot stream and video stream will be uploaded to Intelligent Server 1 and Intelligent Server 2 at the same time. https://i-pro.com/global/en/surveillance/advidia...
You can set this parameter only when Port Mode is set to PTZ Control. When PTZ Protocol is set to INTERNAL-PTZ, the camera can connect to the external PTZ without using the serial port (serial port parameters are greyed out). In this https://i-pro.com/global/en/surveillance/advidia...
This function is not supported by some models. Please see the actual model for details. Make sure that you have set Port Mode to Trans-Channel for your camera. 1. Click Setup>System>Ports & Devices, and then click the Serial Port tab. 2. Select Trans-Channel from the Port Mode drop-down list. https://i-pro.com/global/en/surveillance/advidia...
For more details, contact your dealer. 1. Click Setup>System>Ports & Devices, and then click the Serial Port tab. 2. Select OSD from the Port Mode drop-down list. Select Enable OSD Report (so OSD data will be uploaded to the platform). https://i-pro.com/global/en/surveillance/advidia...
If enabled, both the camera and the boot program are upgraded, and the operating system of the following new versions can be booted properly, and the camera can be upgraded conveniently. Ensure that the power supply is normal during upgrade. The device will restart after the upgrade is completed. https://i-pro.com/global/en/surveillance/advidia...
Export. 4. To restore default configurations, click Default and then confirm the operation. The device will restart and restore the default configurations. Clicking Default with the check box selected will completely restore the device to factory default settings. https://i-pro.com/global/en/surveillance/advidia...
Enter the actual height from the installed infrared dome to the ground, so that the dome will be able to automatically adjust its infrared lamp. NOTE! This function is only supported by some infrared cameras. Please see the actual model for details. 1. Click Setup>System>Maintenance https://i-pro.com/global/en/surveillance/advidia...
Photo Storage Status View the current photo storage status. See エラー! 参照元が見つかりません。 for the full storage policy. NOTE! Only models with storage function support this function. Please see the actual model for details. 1. Click Photo in the Menu https://i-pro.com/global/en/surveillance/advidia...
Live view means playing live video (real-time audio and video) received from a camera in a window through the Web interface. If you log in with the Live View check box selected, live video appears by default when you are logged in. You may double-click the window to enter or exit full screen mode. https://i-pro.com/global/en/surveillance/advidia...
Reset the packet loss rate to zero. Note: After you move the mouse cursor on a live view window, this button appears on the floating toolbar. Display packet loss rate and bit rate information at the bottom of the window. https://i-pro.com/global/en/surveillance/advidia...
Digital zoom enlarges an image with loss in image quality, while 3D positioning enlarges an image without. Using Digital Zoom NOTE! The supported live view operations may vary with camera model. For the operations that your camera supports, see the Web interface. 1. On the Live View page, click on the toolbar https://i-pro.com/global/en/surveillance/advidia...
Using 3D Positioning (Applicable in M-400-P only) NOTE! This function is available only for network PTZ cameras and network box cameras equipped with motorized zoom lens and PTZ. Please see actual models for details. 1. On the Live View page, click on the toolbar https://i-pro.com/global/en/surveillance/advidia...
1. In live view page, click 2. Snapshot list will be displayed on the right of live view, with the latest on top. Up to 200 snapshots will be displayed. The following figure shows an example. https://i-pro.com/global/en/surveillance/advidia...
Page 75
JPEG format. You may also change the image path in Setup > Common > Local Parameters. When the disk space is smaller than 100MB, you will be prompted to clear auto snapshot folder, and new snapshots will not be displayed in live view page until disk space is freed. https://i-pro.com/global/en/surveillance/advidia...
JPEG format. You may also change the image path in Setup > Common > Local Parameters. When the disk space is smaller than 100MB, you will be prompted to clear auto snapshot folder, and new snapshots will not be displayed in live view page until disk space is freed. https://i-pro.com/global/en/surveillance/advidia...
4. Click Open Image Folder to view the snapshots saved in your PC. The snapshots are saved in JPEG format. You may also change the image path in Setup > Common > Local Parameters. When the disk space is smaller than 100MB, you will be prompted to clear https://i-pro.com/global/en/surveillance/advidia...
(local path can be changed in Local Settings). 4. Click Open to show the folder where the downloaded video is saved. PTZ Control This function is available only for the PTZ dome cameras or a box camera installed on a Pan/Tilt motor. https://i-pro.com/global/en/surveillance/advidia...
Control the direction of the PTZ camera and release the control. Turn on or off IR. Turn on or off the wiper. Turn on or off the heater. Turn on or off the illuminator. Turn on or off snow control. Adjust camera focus. Adjust camera zoom. https://i-pro.com/global/en/surveillance/advidia...
2. Adjust the camera till it points toward the desired direction. 3. Adjust zoom and focus as needed to obtain the optimal image. 4. Click to add it as a preset. Enter a number and name for the preset and then click OK. https://i-pro.com/global/en/surveillance/advidia...
1. On the Live View page, click Preset on the control panel. 2. Click for a preset. The PTZ camera goes to the selected preset. Delete a preset 1. On the Live View page, click Preset on the control panel. 2. Click for a preset and then confirm the delete. https://i-pro.com/global/en/surveillance/advidia...
Rotate at the set speed in the set direction for a certain amount of time, zoom, stay at a set position for a certain amount of time, or patrol repeatedly if Keep Rotating is selected. It is recommended that the first action type is Go to Preset. 4. Click OK. https://i-pro.com/global/en/surveillance/advidia...
Then the patrol route is saved as a mode route automatically. You can click to start patrol or to delete the mode route. Make a patrol plan 1. On the Live View page, click Patrol on the control panel. https://i-pro.com/global/en/surveillance/advidia...
Start a patrol route 1. On the Live View page, click Patrol on the control panel. 2. Click for the patrol route you want to start. Edit a patrol route 1. On the Live View page, click Patrol on the control panel. https://i-pro.com/global/en/surveillance/advidia...
PTZ camera will return to home position if no operation is made within a specified period. NOTE! This function is available for network PTZ cameras only. You need to add presets or a patrol route first. See Add a preset and Add a patrol route for details. https://i-pro.com/global/en/surveillance/advidia...
3. Click Save. PTZ Limit Set rotation limits to prevent the PTZ camera from hitting obstacles such as a wall. NOTE! This function is only supported by some PTZ cameras. 1. Click Setup>PTZ>PTZ Limit. https://i-pro.com/global/en/surveillance/advidia...
Repeat the above steps to set all limits as needed (up, down, left, right). Click Save. Click Start PTZ Limit to apply the setting. Click to delete settings and reset the limit. Resume Patrol Click Setup>PTZ>Patrol. Set the time when patrol resumes. Click Save. https://i-pro.com/global/en/surveillance/advidia...
Page 88
Daylight Saving Time File Transfer Protocol Group Of Pictures Graphical User Interface HTTPS Hyper Text Transfer Protocol over SSL Internet Explorer IMOS IP Multimedia Operation System Internet Protocol IP Camera Maximum Transmission Unit Network Time Protocol On Screen Display https://i-pro.com/global/en/surveillance/advidia...
Page 89
Run as administrator, and then install it according to instructions. What to do if live video fails when I log in for the first time Answer: Close the firewall on your PC and then log in to the Web interface again. https://i-pro.com/global/en/surveillance/advidia...
