Summary of Contents for advidia M-46-FW-V2
- Page 1 M-46-FW-V2 Network Fixed Dome Cameras Quick Guide V1.01...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! ⚫ Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessory （3） User manual Remarks: * means optional and supplied with certain models only. -
Page 5: Maintenance
⚫ Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. ⚫ When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. -
Page 6: Cable Connection
79.4mm (3.1'') Cable Connection The appearance and tail cable may vary with device model. Audio input (Sound pickup) Audio output (Outdoor sound box) Network Alarm Alarm input output Network access (Voice (Alarm device activated indicator) Power connected switch) adapter through copper interface Mount Your Camera (Optional) Insert Micro SD Card... -
Page 7: Ceiling Mount
Ceiling Mount You can adopt wall mount or pendant mount and purchase hardware accessories separately. The following part takes wall mount as an example. Pendant mount is similar to wall mount and therefore is omitted here. Locate the positions of the holes. Paste installation positioning stickers on the ceiling and lead the cables through the hole on the wall. - Page 8 Mount the camera. Connect all cables of the ceiling and the camera, lead self- tapping screws through the guide holes in the camera base, and fix the camera on the ceiling by using a screwdriver. Adjust the monitoring direction of the lens (tighten screws after vertically adjusting the lens).
- Page 9 Buckle on the base 3-Axis: For 3-Axis, after adjusting the lens horizontally and vertically (see step 5), you can also rotate the lens clockwise or counterclockwise to get the desired monitoring direction. Please stop rotating the camera when the lens is blocked, otherwise the camera lens might be damaged.
-
Page 10: Access Your Camera
Base buckle Groove NOTE! ⚫ The preceding installation process is concealed installation, during which holes are drilled in the ceiling and tail cable is led out from the top of the camera. Cables are connected and frapped at the ceiling side to prevent messy cables from affecting camera mounting. - Page 11 In the login page, enter the default username and password (admin/123456), then click Login. NOTE! ⚫ DHCP is enabled by default. If a DHCP server is used in your network, your camera may be assigned an IP address, and you need to use the assigned IP address to log in.
- Page 12 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
-
Page 13: Network Security
and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. ⚫ Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus. - Page 14 ⚫ Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. ⚫...
-
Page 15: Regulatory Compliance
⚫ Use a UL certified power supply that meets LPS requirements if an adapter is used. ⚫ Use the recommended cordset (power cord) in accordance with the specified ratings. ⚫ Only use the power adapter supplied with your device. ⚫ Use a mains socket outlet with a protective earthing (grounding) connection. ⚫... - Page 16 2013/56/EC. For proper recycling, return the battery to your supplier or to a designated collection point. © i-PRO Co., Ltd. All Rights Reserved. i-PRO, Viewnetcam.com, Advidia, VideoInsight, CloUDE, and Unified Digital Evidence are registered trademarks or trademarks of i-PRO Co., Ltd. or i-PRO Americas Inc. in various jurisdictions. All other trademarks are the...
