- Page 1 M-87-V Network Fixed Dome Cameras Quick Guide V1.00...
- Page 2 Waterproof Requirements Please waterproof cables in accordance with the following instructions. User shall assume all responsibility for device damage caused by water due to improper waterproof measures. NOTE! Before you start, connect all the needed cables and cut off the copper wires for the cables that you don't use.
- Page 3 Tighten Tighten Tighten Waterproof tape Wrap the unused cables together into a bundle 3. Install the supplied waterproof components to the network cable in sequence. CAUTION! You need to mount the rubber ring onto the network cable interface first. 4. If your camera has a DC cable and you will not use it, insert the plug into the interface.
-
Page 4: Packing List
Packing List Contact your local dealer if the package is damaged or incomplete. The attachments may vary with models, please see the actual model for details. Name Unit Camera Waterproof components （1） Screw components （2） Mount accessory （3） User manual Remarks: * means optional and supplied with certain models only. -
Page 5: Maintenance
Do not overbend the cables during the installation, otherwise, poor cable contact may cause malfunction. When connecting to an external interface, use an existing connection terminal, and ensure that the cable terminal (latch or clamp) is in good condition and properly fastened. - Page 6 Φ 134.0mm (5.3") 111.3mm (4.4") Φ 4.6mm (0.18") Cable Connection The appearance and tail cable may vary with device model. 1. Audio input/Audio output/GND 2. Alarm input(IN,GND)/ Alarm output(N,P) 3. Power interface 4. Ethernet interface...
-
Page 7: Internal Structure
Internal Structure Transparent dome cover Safety wire Reset button Micro SD card slot NOTE! Use a pin to press and hold the Reset button for about 15 seconds to restore factory default settings. Perform this operation within 10 minutes after the device is powered on or the reset will fail otherwise. - Page 8 Locate the positions of the holes. Paste installation positioning stickers on the ceiling and lead the cables through the hole on the wall. Paste the drill template and lead the cables through the hole. Use a Ø6mm- 6.5mm drill bit to drill 30 mm-depth guide holes according to the template.
- Page 9 Mount the transparent dome cover. Align the screw holes in the base, and tighten the three torx screws on the edge of the transparent dome cover to fix it. NOTE! The preceding installation process is concealed installation, during which holes are drilled in the ceiling and tail cable is led out from the top of the camera.
-
Page 10: Access Your Camera
Access Your Camera Open your Web browser, enter the camera's IP address in the address bar, and then press Enter. The default IP is 192.168.1.13. In the login page, enter the default username and password (admin/123456), then click Login. NOTE! DHCP is enabled by default. - Page 11 Disclaimer and Safety Warnings Copyright Statement No part of this manual may be copied, reproduced, translated or distributed in any form by any means without prior content in writing from our company (referred to as us hereafter). The product described in this manual may contain proprietary software owned by our company and its possible licensors.
- Page 12 and recommendations in this manual are presented without warranty of any kind, expressed or implied, including, but not limited to, merchantability, satisfaction with quality, fitness for a particular purpose, and noninfringement. l Users must assume total responsibility and all risks for connecting the product to the Internet, including, but not limited to, network attack, hacking, and virus.
- Page 13 l Choose username and password discretely: Avoid using the username and password of your social media, bank, email account, etc, as the username and password of your device, in case your social media, bank and email account information is leaked. l Restrict user permissions: If more than one user needs access to your system, make sure each user is granted only the necessary permissions.
- Page 14 l Use a UL certified power supply that meets LPS requirements if an adapter is used. l Use the recommended cordset (power cord) in accordance with the specified ratings. l Only use the power adapter supplied with your device. l Use a mains socket outlet with a protective earthing (grounding) connection. l Ground your device properly if the device is intended to be grounded.
- Page 15 to cause harmful interference in which case the user will be required to correct the interference at his own expense. LVD/EMC Directive This product complies with the European Low Voltage Directive 2014/35/EU and EMC Directive 2014/30/EU. WEEE Directive–2012/19/EU The product this manual refers to is covered by the Waste Electrical & Electronic Equipment (WEEE) Directive and must be disposed of in a responsible manner.
