Mercedes-Benz
10.25" Android Multimedia HD
installation manual
installation manual
For:A/CLA/GLA NTG5 Audio20 or Comand system
SUNE TECHNOLOGY ELECTRONIC CO.,LTD
No.9,Lane 606,Anping Rd,Tainan City
70849,TAIWAN
TEL:+88662292246 FAX:+88662288104
Http://www.sune-tech.com
Shop http://www.carnavi-tech.com
SKYPE:sune_tech or hsin_han99
Model:SE-A1025
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Sune Technology SE-A1025
Summary of Contents for Sune Technology SE-A1025
- Page 1 Mercedes-Benz 10.25" Android Multimedia HD installation manual installation manual Model:SE-A1025 For:A/CLA/GLA NTG5 Audio20 or Comand system SUNE TECHNOLOGY ELECTRONIC CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99...
-
Page 2: Specifications
Specifications 1, 10.25 inch Capacitive touch screen 2, HD: 1280X480 3, highlight: 500CD / m2 1 Android Main Function: 1, Technical specifications: A. Operating voltage: DC 12V B. Operating voltage range: 10.8V-16V C. Maximum operating current: 2A D. Standby quiescent current: <6mA E. - Page 3 Specifications 2, Freescale I.MX6A9 quad-core 1GHZ CPU 3, GPS; WIFI; A2DP Bluetooth; 4,1080P HD video playback; 5, high-quality music player; 6, Bluetooth phone, Bluetooth music 7, mobile Internet; (iphone) 8, to support driving recorder installation: you can access video recorder video; can also be installed by driving recorder APP, WIFI connected through the HD display driving recorder image and touch control driving recorder operation 9, support voice control;...
- Page 4 Installation(For W246/176/117/W156) How to Resolution your system NTG4.5/4.7 system NTG5 system PS:Make sure your system before order...
- Page 5 Installation(For W246/176/117/W156) Installation tools: plastic skid plate, plum wrench hand T20, wrenches T20 (short / L-shaped), Phillips screwdriver, a small screwdriver, electric tape Before installed After installed。 1、As shown: Remove these two cap with hexagonal 2 Lo, T20 screw down the two screws and remove the screen 4、As shown：Use T20 2、As shown in the figure: Pry the 3.As shown in the figure: the air conditioning outlet with pry lever pry down.
- Page 6 Installation(For W246/176/117/W156) Amplifier box mounting position 8,as shown:Remove the glove box 9.As shown: Use Plug play 10, as shown in the figure: the amplifier box is inserted in the line fixed to 5 screws . connector to the original connector the right Radio screws.
- Page 7 Installation(For W246/176/117/W156) 18.As shown: Camera installation operation, remove the original car 19、install camera wiring room。 decoration, Note the buckle. 23.install back camera 24.camera finished 25.finished 20.connection camera cable 。...
- Page 8 Exterior Main 10.25" Android system Back of Android system 1pcs Amplifier box for Android 1pcs Speaker 1pcs Antenna system USB MP3 Audio output 1pcs Wiring room harness...
- Page 9 Diagram 1.Amplifier box connection 16P and 20P connector into Amplifier box "TFT CON" and "CAR CON" 2.Android system monitor Connection Antenna and Blue Connection 24P connector into monitor LVDS cable into screen...
- Page 10 Diagram Remove original connector Plug Play male connector into plug & play Female into headunit connector 1.Empty 6.CAMERA for camera input 7.SPK for speaker 2.B+12V for add decive 8.BRAKE to GND 3.CCD 12V for add Rear camera Red or both Red+yellow 9.ADAS empty 4.ACC OUT +5V 10.GND...
- Page 11 For add camera power connection Yellow and Red both to No.3 CCD Others wire was empty no use...
