Last Updated : 2011.08.23
MODEL : QVL-MB10-RND-V1 / Product code : MB10-RND-V1-1001-000
MB10
(W221 2010 MODEL)
Specification & Installation
SUNE TECHNOLOGY ELECTRONIC CO., LTD
No.9, Land 606,Anping Rd., Tainan City 70849 Taiwan
Tel: +886-62292246 Fax:+886-62288104
Website http://www.sune-tech.com
Shop http://www.carnavi-tech.com
Skype : hsin_han99 or sune_tech
Your best partner for better driving
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sune Technology MB10
Summary of Contents for Sune Technology MB10
- Page 1 Last Updated : 2011.08.23 MODEL : QVL-MB10-RND-V1 / Product code : MB10-RND-V1-1001-000 MB10 (W221 2010 MODEL) Specification & Installation SUNE TECHNOLOGY ELECTRONIC CO., LTD No.9, Land 606,Anping Rd., Tainan City 70849 Taiwan Tel: +886-62292246 Fax:+886-62288104 Website http://www.sune-tech.com Shop http://www.carnavi-tech.com Skype : hsin_han99 or sune_tech...
-
Page 2: Table Of Contents
Contents 1. Before installation 1.1 Main Specification 1.2 Features 1.3 System diagram 1.4 Components 1.5 Exterior 2. Setup 2.1 DIP switch 2.2 Remote control usage 2.3 Power cable 2.4 Setup for car model & navigation 2.5 Parking guide line 2.6.1 OSD (on screen display) 2.6.2 OSD (on screen display) 2.7 Switching Mode via CAN wire 3. -
Page 3: Main Specification
1.1 Main specification 1. Input Spec. (MULTI VIDEO INTERFACE) -. 1 x Analog R,G,B (Sync on Green) -. 1 x CVBS(NTST & PAL Auto Detect) Input. (Rear camera source) -. 3 x CVBS(NTST & PAL Auto Detect) Input. (A/V source) -. -
Page 4: Features
1.2 Features - More convenience to install with plug & play (HSD cable offered) - Possible to move the displayed position of DVD, Navi - NAVI Model Selection (WQVGA, WVGA) - +12V Output ( From Navi, AV1 , Rear (For Rear Camera power) -
Page 5: System Diagram
1.3 System diagram Remote control Switch for source toggle OEM Navi Button (Can Interface) NAVIGATION Input (Analog RGB) DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) Car Screen Input POWER A/V OUT (CAR MAIN BOARD) FMTX... -
Page 6: Components
1.4 Components LCD cable * 1ea IR cable * 1ea LVDS cable * 1ea SUB BOARD* 1ea REMOTE CONTROL * 1ea AV cable * 1ea RGB cable * 1ea SEL cable * 1ea MODE cable * 1ea POWER cable (7P) * 1ea... -
Page 7: Exterior
1.5 Exterior ⑥ ⑦ ⑧ ⑨ Dimension Horizontal length 153mm Vertical length 90mm Height 21mm ① POWER/CAN ② SEL OUT ③ MODE ④ RGB(IN) ⑤ A/V (IN/OUT) ⑥ LED ⑦ DIP switch ⑧ IR ⑨ LVDS OUT ① ② ③ ④... -
Page 8: Dip Switch
2.1 DIP switch ※ ON : DOWN / OFF : UP #PIN FUNCTION DIP S/W Selection ※DIP S/W Use Example ON : Skipping RGB Mode RGB INPUT MUTE OFF : RGB Display -. Use Input Mode : A/V3(DVD),Navigation (RGB) ON : Skipping A/V 1 A/V 1 MUTE -. -
Page 9: Remote Control Usage
2.2 Remote control usage Function POWER & PIP Unavailable MENU Activating OSD menu Making a selection, changing image display ▲ Moving upward ▼ Moving downward Moving leftward ◀ (If you press this button 5 seconds long, you can get access to the factory mode.) Moving rightward ▶... -
Page 10: Power Cable
2.3 Power cable FILTER & FUSE BOX ACC : 8v~18V CAN(H) CAN(L) F-CAM-DET (Not for use) SAFE REAR-C... -
Page 11: Setup For Car Model & Navigation
2.4 Setup for car model & navigation FACTORY mode – Press ◀ button 5 seconds long or press ▲ → ▼ → ▲ →MENU on the remote control. IMAGE UTIL - NAVI MODEL Adjusting the position of Navigation 해상도 navigation - DEFAUTL * H-POSITION - KD680-NEW (for China) -
Page 12: Parking Guide Line
2.5 Parking guide line setting FACTORY mode – Press ◀ button 5 seconds long or press ▲ → ▼ → ▲ →MENU on the remote control. PARK PARK - ENABLE PARK - ENABLE * PARK ENABLE : Selecting whether to A. -
Page 13: Osd (On Screen Display)
2.6.1 OSD (on screen display) Analog RGB Mode IMAGE COLOR UTIL * BRIGHTNESS * RED : Adjusting red * LANGUAGE : Choosing * FACTORY RESET : interface language while Resetting all the data about * CONTRAST * GREEN : Adjusting green changing mode between the relevant mode that A/V and DVD... -
Page 14: Osd (On Screen Display)
2.6.2 OSD (on screen display) Video mode IMAGE UTIL * BRIGHTNESS * LANGUAGE : Choosing interface * FACTORY RESET : Resetting all language while changing mode the data about the relevant mode * CONTRAST between A/V and DVD that applicable to navigation, DVD mode respectively. -
Page 15: Switching Mode Via Can Wire
2.7 Switching mode via CAN wire After wiring CAN of the car with offered CAN cable, you can switch A/V mode by the Factory button as below. W221 2010model 8”(NEW S-Class) : Switching Mode by “Navi/Tel” Button as shown left. Black : CAN LOW (Green) Black+White: CAN HIGH (Green+Brown) •... -
Page 16: Installation Diagram
3.1 Installation diagram CAN High Control Box CAN Low Monitor Original LCD cable Offered LCD cable DIP S/W Remote LVDS-OUT VIDEO INTERFACE (W221/W204) MODE POWER SET OUT RGB(IN) A/V(IN/OUT) REAR-C SAFE F-CAM-DET CAN-L CAN-H ACC (12V ~24V) -
Page 17: Cautions On Installation
3.2 Cautions on installation Ignition key should be taken off before starting installation, interface power connection must be the last step in installation. Power cable should be separated when connecting interface. Should be no any electronic devices or magnetic pole around installation place. ... - Page 18 3.3 설치(New S, C-class LCD IN/OUT cable connection Connect the Original LCD cable into LCD-IN input of the interface board and offered LCD-Out cable into the Monitor. CAN wire connection Connect offered CAN wires to CAN wires from car. - White + Black : CAN High - Black : CAN LOW...
-
Page 19: Troubleshooting
4. Troubleshooting 1. When can not change mode. -. Check if the IR Cable (remote control) is connected or not. -. Check if LED is turned on or not. If it is not turned on, Check if power cable is connected or not. -.
