- Page 1 Installation Manual Multimedia Interface for Mercedes Benz NTG5.0/NTG5.1...
- Page 2 Compatibility: Mercedes Benz NTG5.0, NTG5.1 2014~ S-CLASS (W222) 2014~ C-CLASS (W205) 2014~ E-Class, GLE, GLC, A, V class 2015~ B-Class (W246) 2015~ CLS Class 2015~ Components: Interface Main*1 Sub Board*1 Interface Input / Output specification : Input: LVDS*1 CVBS(Front Camera)*1...
- Page 3 Main Board Power Cable QLI J BY J Cable LVDS Cable QCPASS1411 HPOWER0240 HPOWER0248 HLVDSC0069 Sub Board LCD Out Cable T/S Out Cable Res. T/S Cable Cap. T/S Cable QCPASS1403 HLCDCA0017 HTOUCH0009 HTOUCH0029 HTOUCH0036 UART T/S Out Cable Button Cable Remote Controller IR Cable HTOUCH0015...
-
Page 4: Monitor Type
STATUS DESCRIPTION LVDS Navigation Mode DIP1 LVDS Navigation Mode Skip Ext. Front Camera Mode DIP2 Ext. Front Camera Mode Skip NTG5.0 CAN Speed DIP3 NTG5.1 CAN Speed DIP4 No Use DIP5 Please refer below chart DIP6 OEM Rear Camera Mode DIP7 Ext. - Page 5 FUNCTION POWER & PIP MENU Activating OSD menu Making a selection, changing image display ▲ Moving upward ▼ Moving downward Moving leftward ◀ (If you press this button 2 seconds long, you can access the factory mode) Moving rightward ▶ (If you press this button 2 seconds long, you can reset all the data about user environment)
- Page 6 Menu of FACTORY IMAGE IMAGE H-POSITION PARK V-POSITION H-POSITION/V-POSITION Setting UTIL1 UTIL2 INFO MENU to Return SEL to Select/Save Menu of FACTORY IMAGE PAS TYPE PARK PAS SETUP UTIL1 REAR TYPE UTIL2 RADAR ENABLE INFO AUTO FCAM TIME MENU to Return SEL to Select/Save PARK PAS TYPE: Select parking line type.
- Page 7 CAR MODEL: Select the car model ASTON(TYPE1) MENU to Return SEL to Select/Save ASTON(TYPE2) NTG5.1 CLS NTG5.1 CLA NTG5.1 B-CLASS NTG5.0(TYPE2) NTG5.0(TYPE1) UTIL2 Menu of FACTORY IMAGE HANDLE BUTTON HANDLE BUTTON: Select the usage of handle button PARK FACTORY RESET...
- Page 8 * Press high lighted OEM button for 3 seconds long to mode switch S Class C Class...
- Page 9 1. QDIS supplied LCD out cable from OEM Command to sub-board “LVDS IN” 2. OEM LCD cable from back side of OEM Monitor to Monitor sub-board “To Monitor” EXT. touch screen 3. QDIS supplied LVDS cable from sub-board “LVDS OUT” ❷...
- Page 10 ① ② Find the connector behind the command Remove the black connector which is marked in ③ ④ Disassemble the black plastic cover Connect OEM cables to the supplied CAN IN/OUT cables ⑤ ⑥ Insert the supplied CAN cables into the marked Put the black plastic cover and the supplied CAN IN/OUT cables together place...
- Page 11 * These functions can be used when SE-CP or NV-CP is installed with. ⑥ ⑥ ④ ⑤ ① ① ④ ⑤ ⑦ ③ ② ⑥ ⑦ ③ ② ① ⑤ ④ ⑦ ③ ② C Class S Class Section No. Button Operation Function...
- Page 12 Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
- Page 13 SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX: +88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Copyright ⓒ 2019 by SUNE TECHNOLOGY...
