- Page 1 Your best partner for better driving SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99...
- Page 2 Index 1. General spec 2. System Diagram 3. Components 4. Setting up Dip S/W 5. Setting up FACTORY MENU 6. Cautions before Installation 7. Installation Diagram 8. Installation 9. Quality Warranty...
-
Page 3: Warning / Precautions
Warning / Precautions! Do not modify, dismantle or unintended operation this system outside Q-roi After Sales. Damage occured by unintended operation may Warning cause Q-roi After Sales service void. Always wear seatbelt. When the vehicle is suddenly stop can cause injury. Warning ... -
Page 4: General Spec
1. General Spec Android 4.2.2 (Jelly Bean) Telechips TCC8930 (1GHz Cortex A9 DualCore) Display OEM LCD Internal Memory DDR3 1GB RAM + 8GB eMMC External Memory SDHC Slot Support (up to 64GB) A/V Input x 3, Rear Cam Input x 1, CAN(Controller Area Network) x 2, Function Mic x 1,... -
Page 5: System Diagram
2. System Diagram LCD Display eMMC LVDS Flash USB HUB Transmitter Memory USB Devices - USB memory - Hard Disc - Wifi dongle - BlueTooth dongle - 3G / LTE dongle - Other USB Touch Accessories DDR3 Screen Application Touch Image Scaler Controller Processor... - Page 6 3. Components LVDS cable * 1ea LCD Cable * 1ea (HLVDSC0014) (HLCDCA0019) 3G dongle * 1ea(Option) (ETCETC0116) TOUCH IN cable * 1ea WIFI dongle * 1ea(Option) (HTOUCH0009) I/F Board * 1ea (ETCETC0110) Power cable 16P * 1ea (HPOWER0041) AV/BT Cable * 1ea USB cable * 2ea (HAVCAB0020) (HARETC0027)
- Page 7 4. Setting up Dip Switch(I/F) ※ Example DIP S/W usage - Size of Monitor : 8.8”,10.2” - Standard version of GUI - External rear camera ▷DIP S/W : 1,2 ,3,4 OFF ▷DIP S/W : 5 OFF (8.8” & 10.2”) ※...
- Page 8 4. Setting up Dip Switch (Main board) : Select Memory button using(Dip S/W #3) ON : MINI – #6 button using OFF : The others - #8 button using ※ ON : DOWN / OFF : UP...
- Page 9 5. Setting Factory Menu ※ APPS→FACTORY SETTING ① Put Password and change program upgrade and set-up of external device. (Only Installers are authorized) ※ Please contact the manufacturer to get Password.
- Page 10 5. Setting up Factory Menu ⑤ ④ ① ② ③ ① CAR MODEL : No use ② DVD TYPE : Only for DVD connected to A/V (Connect IR-AV1 to DVD to use DVD as touch Screen) ③ CMMB SELECT : Select DTV model ( Only Chinese) ④...
-
Page 11: Cautions Before Installation
6. Cautions before Installation Ignition key should be taken off before starting installation, interface power connection must be the last step in installation. Power cable should be separated when connecting interface. Should be no any electronic devices or magnetic pole around ... -
Page 12: Installation Diagram
7. Installation Diagram ※ 모니터에서 꽂혀있던 순정 LCD 케이블(라디오 시스템과 연결된)을 빼서 I/F 보드의 LCD-IN에 연결하고, 자사가 제공한 LCD 케이블을 모니터(순정 LCD 케이블을 뺀 자리)에 연결합니다. <Behind of Radio System> Speaker Original LCD Cable Provided LCD Cable SAFE FRONT Monitor CAN1-H REAR CAN1-L... -
Page 13: Installation
8. Installation 8.1 Connection Monitor to Interface ① Remove the original LCD cable from the monitor and connect the provided LCD cable as the photo Provided LCD cable ② Connect the original LCD cable to LCD- IN of Interface. ※ Cautions : Do not connect Power cable to behind the Command or Cigar Jack power instead of ACC. - Page 14 8. Installation 8.2 Connection of CAN wire OEM CAN-Low OEM CAN-High <Q-ROI MAIN BOARD> Provided CAN1-High Power cable Provided CAN1-Low Behind of Radio System Please refer to the above diagram. Connect CAN1-H(Yellow + White) to CAN-H(Yellow + Red) of Car. Connect CAN1-L(White) to Original CAN-L(Yellow + Brown).
-
Page 15: Quality Warranty
9. Quality Warranty This product has been tested and have passed under our strict quality control. If the failure occurred due to the carelessness of workmanship within one year after the purchase, we are responsible to repair free of charge. Please bring this warranty to dealer whom you purchased this product from at the repair time.
