- Page 1 Quick Start Guide SpeedFace - V5L Version: 1.0 Due to regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Installation Environment
Overview Flash Camera & Palm collector Microphone 5" touchscreen Terminal block Fingerprint sensor & Magnetic Card reading area tamper switch Auxiliary input Power in Reset Speaker RXD2 Sensor TXD2 RS232 Ethernet ExitButton +12V IWD0 RS232 Lock Wiegand IWD1 485A Wiegand RS485 Alarm 485B... -
Page 3: Device Installation
Device Installation ① 1.5m ② ① Attach the mounting template sticker to the wall, and drill holes according to the mounting paper. Fix the back plate on the wall using wall mounting screws. ② Attach the device to the back plate. ③... -
Page 4: Lock Relay Connection
Door Sensor, Exit Button & Alarm Connection SmokeDetector Door Sensor ExitButton Alarm's power switch Alarm Lock Relay Connection The system supports Normally Opened Lock and Normally Closed Lock. The NO LOCK (normally opened at power on) is connected with 'NO1' and 'COM' terminals, and the NC LOCK (normally closed at power on) is connected with 'NC1' and 'COM' terminals. - Page 5 RS485 and RS232 Connection RXD2 RS232 TXD2 Reader RS232 Reader RS485 485+ 485A Reader 485- 485B Wiegand Reader Connection +12V IWD0 IWD1 Wiegand Reader Access controller...
-
Page 6: Power Connection
Power Connection 12V DC Recommended power supply 1. 12V ± 10%, at least 3000mA. 2. To share the power with other devices, use a power supply with higher current ratings. Ethernet Connection ZKBioSecurity RJ 45 IP address: 192.168.1.130 Subnet mask: 255.255.255.0 Default IP address: 192.168.1.201 Subnet mask: 255.255.255.0 Click [COMM.] >... -
Page 7: User Registration
User Registration When there is no super administrator set in the device, click on to enter the menu. After setting the super administrator, the system will request for the administrator’s verification before entering the menu. For the security purpose, it is recommended to register a super administrator at the first time you use the device. -
Page 8: Ethernet Settings
Ethernet Settings Clickon > [COMM.] > [Ethernet]to set the network parameters. If the TCP/IP com- munication of the device is successful, the icon will be displayed in the upper right corner of the standby interface. Main Menu Comm. Ethernet Ethernet IP Address 192.168.163.201 User Mgt. - Page 9 LAN Video Intercom Function Settings Step 1: Install the ZKBioSecurity software and ZKBio VMS Plugin 1. Choose the "Video-VMS" module of the ZKBioSecurity software to install. (The Video module and the Video-VMS module cannot be installed together.) 2. Install the ZKBio VMS Plugin. (To recognize the intercom function, the ZKBioSecurity software and the ZKBio VMS Plugin must be opened simultaneously.) Configuration Parameters...
- Page 10 3. Configure the parameters on the device a. Click on > [COMM.] > [Cloud Server Setting] to set the server address and server port, that is, the IP address and port number of the server after the software is installed. The icon is displayed in the upper right corner of the standby interface when the device communicates with the server successfully.
- Page 11 Step 3: Adding device on ZKBioSecurity software a. Click [Access] > [Device] > [Device] > [Search] to add the device on the ZKBioSecurity software. b. After the device is added successfully to the access module, it automatically adds to the video module. User can click [Video] > [Video Device] > [Search] to view. (If the device is not added to the Video module, please check whether the parameter settings are correct.)
- Page 12 Step 4: Video Preview Click [Video] > [Real-Time] > [Video Preview] to enter the preview interface of the device. Step 5: Device Call Click on icon on the main interface of the device to get to the call window. The user can click icon to accept the call, click icon to take a snapshot, or click...
- Page 13 Connect to ZKBio Talk a. Keep the parameter settings of ZKBioSecurity software unchanged. And then install the ZKBio Talk software. b. Click on > [System] > [Video intercom parameters] > [Intercom Server Setting] on the device, to change the server address and server port. Server Address: Enter the current server installation IP address.
- Page 14 Connect to ZKView After downloading and installing the ZKView APP on the phone, open the APP and add the device by scanning the QR code. Click [System] > [Video intercom parameters] > [QR code binding] on the device to enter the QR code interface. The process is as follows: Video Door Phone Connection Visitors need to press the on the device to get to the call window, and the phone...
- Page 15 ZKTeco Biometrics India Pvt Ltd. Address :B-1, Khata No.31, Devasandra Industrial Estate, Whitefield Main Road, Beside Phoenix Mall, Mahadevapura, Bengaluru - 560048, Karnataka, India Phone : 080 6828 1342 www.zkteco.in Copyright © 2021 ZKTECO CO., LTD. All Rights Reserved.
