Specification; Ports & Interfaces; Ambient Temperature; Physical Characteristics - SC&T IP01 User Manual

IP01H：Ethernet Switch with 4Port 10M + 1Port 10/100M
4 Port Ethernet Switch with 4 ports BNC and 1 port RJ45.
RJ45 terminal support 10/100Mbps auto detect function
BNC terminal support 10Mbps, must work with IP01.
LED indication: Link/Active, Power.
Complies with standard IEEE802.3 and IEEE802.3u.
Auto MDI/MDI-X auto cross at RJ45 terminal.

Specification

ITEM NO.
Support
Transmission Distance
Network Bandwidth
Ports & Interfaces
Input
Output

Ambient Temperature

Operation
Storage
Humidity

Physical Characteristics

Dimensions
Weight
IP01
300M
10/ 100Mbps
1 x RJ45
1 x BNC
0 to 55℃
-20 to 85℃
Up to 95%
64 x 25 x 22mm
25g
User Manual
IP01
2
