- Page 1 IP/ PoE Extender User Manual Model : IP09P PoE over CAT5e Extender Smart Cabling & Transmission Corp. V1.0_201210M...
-
Page 2: Installation View
IP09P Introduction IP09P is a point-to-point PoE (Power over Ethernet) extender that can use single CAT5e (or greater) cable to extend TCP/IP signal and huge amount of power for a remote PoE device, such as speed dome camera, Dante PoE speaker, smart LED…etc., with no external power required. It’s a perfect solution for CCTV system, large-scale audio environment, smart building and factory. - Page 3 User Manual IP09P Extra Power supply at the transmitter side for additional 100M extension Extra-long distance PoE Extension...
- Page 4 To update firmware. DIP Switch To select the desired mode (Refer to Description 5) RJ45 Connector Port 1；To connect with an networking device or IP09P (Refer to Description 4) RJ45 Connector Port 2；To connect with IP09PT/ IP09PR PoE LED Indication...
- Page 5 User Manual IP09P Description Power LED Indication Green ON Green OFF Breathe Power On Power Off Power Saving PoE LED Indicator Blue ON Blue OFF Connect to PoE device Connect to Non-PoE device Status Indication □ 1 Status Port Blue ON...
- Page 6 User Manual IP09P RJ45 Pinout 568B Pinout RJ45 Port 1 (Black) RJ45 Port 2 (Yellow) Order Data Data 1. Orange-white TX+ (DATA1+) PoE+ (Data Pair) DATA1+ Power + 2. Orange TX- (DATA1-) PoE+ (Data Pair) DATA1- Power + SE-T, 3. Green-white...
- Page 7 User Manual IP09P Power and Transmission Distance The reports below show the extension distance and the amount of power transferred by distance. All statistics get from the result of using the COMMSCOPE 57535-2 (CAT5e 24AWG) cables to test Mode & Data Rate by transmission distance...
- Page 8 User Manual IP09P Power from IEEE 802.3at PoE Switch Input Power Distance Output Power 200M 300M IEEE 802.3at 400M 17.5W PoE Switch 500M 16.5W 600M 700M 800M DIP Switch Setting Port 1 can be set manually and automatically but Port2 can only set automatically.
- Page 9 User Manual IP09P Port 1 Auto-Negotiation Priority Priority Mode 1 (Highest) Long Distance 100Mbps 100BASE-T1 Long Distance 10Mbps 100BASE-TX Full Duplex 100BASE-TX Half Duplex 10BASE-T Full Duplex 7 (Lowest) 10BASE-T Half Duplex...
-
Page 10: Jumper Settings
User Manual IP09P Jumper Settings adjust the jumpers. We strongly recommend those who have advanced engineering skills to Improper adjustment may make the devices damaged. Any changes should start after turning off the power. IP09PT Jumper Settings: Position Function Setting Description Jumper cap on pin 1 &... -
Page 11: Package Included
User Manual IP09P IP09PR Jumper Settings Position Function Setting Description Jumper cap on pin 1 & 2 PoE power ON (Default) Operation Mode Jumper cap on pin 2 & 3 PoE power OFF Jumper cap on pin 1 & 2 Support 802.3bt 90W (Default) -
Page 12: Specification
User Manual IP09P Specification: ITEM IP09PR IP09PT Support IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3bw 100BASE-T1 Ethernet IEEE 802.3 N-Way Auto-Negotiation Compliance IEEE 802.3x Full Duplex Operation and Flow Control IEEE 802.3az Energy Efficient Ethernet IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus...
