STEPP II GETTING STARTED
Figure 3: Using Microsoft Windows™ Hyper Terminal
Assign the name for a new session on the displayed window (e.g
STEPP_II).
Figure 4: Assign the name for a new session
Choose the correct COM Port and baud rate settings (9600bps, 8 bit, no
parity bit, 1 stop bit).
Hint 1: To control the STEPP II operating with firmware "V2.0RC1", use
the following pre-defined factory settings:
57600
No
None
Hint 2: To control the STEPP II operating with firmware "STEPP II
Firmware V1.6.2", use the following pre-defined factory settings
9600
No
None
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
bps
8
Data bits
Parity bit
1
Stop bit
Flow control.
bps
8
Data bits
Parity bit
1
Stop bit
Flow control.
VERSION 1.00
Page 7
