STEPP II GETTING STARTED
The kit can be setup using the procedure below.
WARNING: Please do not use the previous Stepp Eval-Board (Starter-Kit
for STEPP) for STEPP II terminal. The STEPP II Eval-Board
has a built-in Li-Ion battery which is directly linked to the
"ACCU ON/OFF" switches placed in the Eval-board and to
the VBAT+ pin of STEPP II. This pin (on the STEPP II) has
in no case to be connected neither to the operating voltage
nor to the GND, else you will damage your terminal.
1. Connect both antenna plugs to the corresponding plugs on the Stepp II
device.
2. Connect the AMP connector on the cable to the AMP header on the
Stepp device. Connect the DB15 plug on the other end of the cable to
the respective socket on the evaluation board.
3. Connect a Molex plug on the cable to the socket on the STEPP II device.
Connect the plug on the other end of the cable to the respective socket
on the evaluation board.
4. Connect the speaker and microphone to the respective sockets on the
evaluation board.
5. Use the serial cable to connect the evaluation board to a serial port on
the PC.
6. Insert the SIM card into the SIM interface of the STEPP II
Connect the power module to the evaluation board and to the ac power
7.
supply.

1.2 Terminal emulator setup

Please ensure that the STEPP II terminal is properly connected to the Eval-
Board and to the host device. Make sure that the STEPP II terminal is
powered on and the GSM LED indicator on the front side of device flashes.
The example below is based on the Windows™ Hyperterminal, because of it
is a supplement tool which is also licensed by purchased Windows™. The
STEPP II can also be configured by using any other Terminal-Program. The
instructions below describe how to use the STEPP II (operating with
Firmware V1.6.2 or V2.0RC1) with a PC running Windows 2000.
On the first time power-up you can use a terminal software which allows the
communication with a modem via RS232 serial port. On Windows 2000,
starts the HyperTerminal program.
