Page 6 - PV to Utility Transfer
Voltage
Page 7 - Utility to PV Transfer
Voltage
Page 8 - Total Max. Charging
Current
Page 9 - Utility Charging Current
CPD1200EO12LCD:
11.0/11.3/11.5/11.8/12.
0/12.3/12.5/12.8V/
ESC
CPD2200EO24LCD:
22.0/22.5/23.0/23.5/24.
0/24.5/25.0/25.5V/
ESC
CPD1200EO12LCD:
FUL/12.0/12.3/12.5/12.
8/13.0/13.3/13.5V/
ESC
CPD2200EO24LCD:
FUL/24.0/24.5/25.0/25.
5/26.0/26.5/27.0V/
ESC
10/20/30/40/50/60/
70A
ESC
10/15/20A
ESC
16
the battery.
1200VA: In PV first condition, battery
11.5V may work with PV to supply
power to the loads, and
2200VA: battery voltage will gradually
23.0V decrease. When battery
voltage reaches the setting
point, the unit will transfer
from PV output to Utility
output.
Note: Make sure the transfer
voltage in P06 is lower than P07.
1200VA: Following Page 6 (P06),
13.5V when utility charges the
battery up to the setting
2200VA: voltage in Page 7 (P07), unit
27.0V will transfer from Utility back
to PV mode.
Note: Make sure the transfer
voltage in P07 is higher than
P06.
1200VA: Max. charging current =
utility charging current +
70A
solar charging current
2200VA:
65A
With different battery
20A
capacity, adjust utility
charging current to provide
optimal recharging time.
