3 DEFINITIONS FOR ILLUMINATED LCD INDICATORS

LCD Display
The left half of the LCD screen displays the energy flow direction and the status of the Power Inverter.
The right half of the LCD screen displays the input, output, and battery information.
Icon
Normal Mode (Power On)
The Power Inverter is turned on.
Standby Mode (Power Off)
The Power Inverter is off while the LCD display remains on.
Utility Power
Utility power source supplies AC power.
Solar Power
Solar power source supplies to load or battery.
Load Capacity
The approximate load capacity of the unit's outlet. (in 25% increments)
Battery Capacity
The approximate battery capacity and charging status. (in 25%
increments)
Fault
This icon appears if there is a problem with the unit.
10
Description
