Line Mode1
The Power Inverter is turned on and AC input power is
normal. It supplies power to the load (connected
equipment).
Line Mode2
The Power Inverter is turned on and AC input power is
normal. It supplies power to the load (connected
equipment) and PV power charges the battery in the
meantime.
Battery Mode1
During a severe brownout or blackout, the Utility Power is
absent and the Power Inverter switches to Battery Mode.
The battery will supply power to the load (connected
equipment).
Battery Mode2
During a severe brownout or blackout, the Utility Power is
absent and the Power Inverter switches to Battery Mode.
The battery and PV panels will supply power to the load
(connected equipment).
