5. ROUTER DESIGN
Sufficient space must be left in front of individual connectors for handling of cables,
Figure 12: Space in front of connectors (plastic)
Figure 13: Space in front of connectors (metal)
For correct function of the router we recommend to use in the switch-board earth-bonding
distribution frame for grounding of power supply of router, data cables and antenna.
11
