Digital Watchdog Snapit DWC-D4365T Manual page 17

EXPOSURE
WDR
(Wide Dynamic Range)
Enables the camera to capture clear images in the same frame,
even when there are both very bright and very dark areas in the
same field.Select from the following options:
LOW / NORMAL / MEDIUM(Factory Default) / HIGH/ CUSTOM
WDR OFF
If CUSTOM is selected, adjust the Bias / Limit as you wish.
- BIAS (-30~30): Decide the WDR level in the range of LIMIT.
The higher the number, the stronger the WDR
adjustment.
- LIMIT (0~36): Decide the range of WDR effect level.
0 means WDR is OFF. The higher the number, the
stronger the WDR will be.
WDR ON
17
