Page 1: User Manual
Indoor Dome Camera DWC-D362D DWC-D362DIR User Manual ABOUT MANUAL Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference. 02222012... - Page 2 PRECAUTIONS Do not open or modify. Do not open the case except during maintenence and installation, for it may be dangerous and can cause damages. Do not put objects into the unit. Keep metal objects and flammable substances from entering the camera. It can cause fire, short-circuits, or other damages.
-
Page 3: Table Of Contents
Table of Contents Introduction Features Parts and Descriptions Dimensions Installation Included Accessories Easy Installations Base Installations Connecting to Monitors Adjusting the Camera Adjusting the 3-Axis Gimbal Camera OSD Menu and Glossary 14-17 Troubleshooting Warranty Information 19-20 Specifications... -
Page 4: Features
FEATURES* DWC-D362D Sharp 1/3” CCD 540 TV Lines 2.8 ~ 11mm Varifocal Auto Iris Lens Electronic Day and Night DRC (Dynamic Range Compressor) HME (Highlight Masking Exposure) SLC (Side Light Compensation) AGC / BLC / AWB Mirror Image Control RS485 Built-In (Optional) Programmable Privacy Zone (4) &... -
Page 5: Features
FEATURES* DWC-D362DIR Sharp 1/3” CCD 540 TV Lines 2.8 ~ 11mm Varifocal Auto Iris Lens 85ft Range IR with Intelligent Camera Sync Electronic Day and Night DRC (Dynamic Range Compressor) HME (Highlight Masking Exposure) SLC (Side Light Compensation) AGC / BLC / AWB Mirror Image Control RS485 Built-In (Optional) Programmable Privacy Zone (4) &... -
Page 6: Parts And Descriptions
PART & DESCRIPTIONS* Lens Power Input Connctor 12VDC/24VAC Dual Voltage Video Output Connector - BNC Upper case Bubble Control board No IR Power board Bottom case Mounting screw... -
Page 7: Dimensions
DIMENSIONS IN MILLIMETERS* Ø 118.0 (Ø4.65”) 3- Ø4.5 (3- Ø0.18”) Ø 89.0 (Ø 3.5”) Ø 20.0 (Ø 0.79”) Ø 118.0 Ø 14.5 (Ø4.65”) (Ø0.57”) - Page 8 INSTALLATION* Included with Value Line Indoor Dome Camera 1. User Manual 3. Second Video Jack 2. Mounting Template 4. Mounting Screw (3) Ø5.0 Mounting template Ø20.0 Ø15.0 Ø118.0 PD79...
-
Page 9: Easy Installations
EASY INSTALLATION* Install the Enclosure Cover To install the dome cover, align the dome cover with the camera base and push until it securely snaps into place. Remove the Dome Cover Before you can mount or adjust your PD79, Dome Cover you must remove the dome cover. -
Page 10: Base Installations
BASE INSTALLATION* 1.Pull wires through and make connections, 2. Adjust the camera’s pan,tilt and zoom. Refer to page 11. Use mounting template to See page 13 for details. mount camera with dry wall mounts and wood screws. 3. Use the joystick to adjust the OSD menu. 4. -
Page 11: Connecting To Monitors
CONNECTING TO MONITORS* 12VDC/24VAC CCTV Monitor Left No IR Down Right 2nd Video Output Monitor 11.8in Power connection - 12VDC/24VAC Dual Voltage.(Auto polarity detection and protection) All camera are equipped with a 2nd video output on the camera Main Board. -
Page 12: Adjusting The Camera
ADJUSTING THE CAMERA* ZOOM FOCUS NO IR Zoom: Tele Wide Focus: Near Loosen the Zoom & Focus Handles by rotating them counter-clockwise. Adjust the Field of view by moving the handle to the RIGHT(Tele) to zoom in, or to the LEFT(Wide) to zoom out. -
Page 13: Adjusting The 3-Axis Gimbal
ADJUSTING THE 3-AXIS GIMBAL* The Gimbal mechanism yields maximum rotation and placement as shown below. Rotation 360º Tilting 70º Panning 360º... -
Page 14: Module Osd Menu
MODULE OSD MENU* EXPOSURE PRIVACY COLOR DAY&NIGHT D&N MODE LENS WB MODE E.SHUTTER R-Y GAIN B-Y GAIN FUNCTION MOTION PRIVACY MIRROR ALARM MASK 1 SHARPNESS MASK 2 GAMMA MASK 3 MASK 4 COLOR SET SETUP EXIT EXIT CAMERA ID SAVE & EXIT TITLE EDIT TITLE RESET FACTORY SET... - Page 15 MODULE OSD MENU AND GLOSSARY* EXPOSURE LENS MANUAL (ELC LEVEL : 0 ~ 100) / DC (DC LEVEL : 0 ~ 31) E.SHUTTER 1/60 / 1/100FLC / 1/250 ~ 100000 / AUTO OFF / ON(Set Level 0~255) BLC (Back Light Compensation) OFF ~ 36dB AGC (AUTO GAIN CONTROL) COLOR...
- Page 16 FUNCTION MIRROR OFF / ON SHARPNESS 0 ~ 49 GAMMA USER / 0.45 / 0.6 / 1.00 OFF / ON (0 ~ 50) SLC (Side Light Compensation) OFF / ON (0 ~ 155) HME (Highlight Masking Exposure) OFF / ON DRC (Dynamic Range Compressor) MOTION OFF / ON...
- Page 17 PRIVACY OFF / ON MASK 1 OFF / ON MASK 2 OFF / ON MASK 3 MASK 4 OFF / ON COLOR SET BLACK / GRAY / COLOR 1~ 6 SETUP CAMERA ID 0 ~ 254 TITLE EDIT TITLE RESET TITLE POS.
- Page 18 TROUBLESHOOTING Before sending your camera for repair, check the following or contact our technical specialist. No VIDEO Check the coaxial cable and make sure it is connected securely. Check the lens’ iris adjustment at the menu setup of the camera. Check the power supply and make sure the camera has the proper voltage and current.
-
Page 19: Warranty Information
WARRANTY INFORMATION* Digital Watchdog (referred to as “the Warrantor”) warrants the Digital Watchdog Camera against defects in materials or workmanship as follows: LABOR : For the initial two (2) years and one (1) year on IR LED from the original purchase date,... - Page 20 LIMITS AND EXCLUSIONS* There are no express warranties except as listed above. The Warrantor will not be liable for incidental or consequential damages (including without limitation or damage to recording media), resulting from the use of these products or arising out of any breach of the warranty.
- Page 21 SPECIFICATION* MODEL DWC-D362D, DWC-D362DIR NTSC General Spec CCD Type 1/3” 410K Pixels Color Total number of pixels 811(H) x 508(V) Min. Illumination 0.1Lux [(F1.2, 24IRE), (at COLOR)] 0.001Lux [(F1.2, 24IRE), (at B/W)] Resolution 540 TV Lines [at COLOR] 580 TV Lines [at B/W]...
