ADJUSTING THE 3-AXIS GIMBAL*
The Gimbal mechanism yields maximum rotation and placement as shown below.
NO IR IR NO IR IR
Rotation 360 Panning 360
NO IR
IR
Tilting 90 Tilting 82
