DEMO MANUAL DC1537A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 4 C2, C3, C22, C23
2 2 C4, C5
3 2 C7, C8
4 2 C10, C11
5 2 C12, C13
6 2 C14, C15
7 2 C16, C17
8 1 C24
9 2 D1, D5
10 2 D2, D4
11 1 L1
12 1 L2
13 2 R1, R2
14 1 R5
15 1 R6
16 2 R7, R8
17 2 R9, R10
18 2 R11, R12
19 2 R13, R14
20 1 R15
21 1 R16
22 1 R17
23 1 U1
Additional Demo Board Circuit Components
1 2 C1, C21
2 0 C6, C9
3 0 C18
4 0 C19
5 0 C20
6 0 C25
7 0 D3, D6
8 0 D7, D8
9 0 R18
10 0 FB1
11 0 L3
Hardware/Components (For Demo Board Only)
1 1 JP1
2 8 TP1, TP2, TP5 TO TP8,
TP16, TP17
3 9 TP3, TP4, TP9 TO TP15 TURRET
4 1 JP1
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , 1210 2.2μF 10% 100V X7R
CAP , 0603 0.47μF 10% 25V X7R
CAP , 1210 100μF 20% 10V X5R
CAP , 0402 22pF 10% 25V NPO
CAP , 0402 0.1μF 10% 16V X7R
CAP , 0402 680pF 10% 25V X7R
CAP , 0402 33pF 10% 25V NPO
CAP , 0402 10nF 10% 16V X7R
DIODE, SCHOTTKY BARRIER SOD123
DIODE, SCHOTTKY RECTIFIER SMB
IND, 22μH
IND, 10μH
RES, 0603 1kΩ 1% 1/16W
RES, 0402 42.2kΩ 1% 1/16W
RES, 0402 24.9kΩ 1% 1/16W
RES, 0402 100kΩ 5% 1/16W
RES, 0402 8.06kΩ 1% 1/16W
RES, 0402 100kΩ 1% 1/16W
RES, 0402 30kΩ 1% 1/16W
RES, 0402 7.32kΩ 1% 1/16W
RES, 0402 20kΩ 1% 1/16W
RES, 0402 40.2kΩ 1% 1/16W
IC, STEP-DOWN REGULATOR
CAP , 22μF 20% 100V OSCON
CAP , 0805 10μF 10% 16V X5R OPTION
CAP , 22uF 20% 100V OSCON OPTION
CAP , 0603 0.01μF 10% 100V X7R OPTION
CAP , 1210 2.2μF 10% 100V X7R OPTION
CAP , 0402 10nF 10% 16V X7R OPTION
DIODE, SCHOTTKY BARRIER SOD123 OPTION
DIODE, OPT
RES, 0603 0Ω JUMPER OPTION
FERRITE BEAD OPTION
IND, 22μH OPTION
HEADER, 4-PIN
TURRET
SHUNT, 2mm
MANUFACTURER/PART NUMBER
AVX 12101C225KAT2A
MURATA GRM188R71E474KA12D
TAIYO YUDEN LMK325ABJ107MM-T
AVX 04023A220KAT2A
TDK C1005X7R1C104K
AVX 04023C681KAT2A
AVX 04023A330KAT
MURATA GRM155R71C103KA01D
ON SEMICONDUCTOR MMSD701T1G
DIODES INC. B360B
NIC NPIM104B220MTRF
NIC NPIM104B100MTRF
NIC NRC06F1001TRF
VISHAY CRCW040242K2FKED
VISHAY CRCW040224K9FKED
VISHAY CRCW0402100KJNED
VISHAY CRCW04028K06FKED
VISHAY CRCW0402100KFKED
NIC NRC04F3002TRF
VISHAY CRCW04027K32FKED
VISHAY CRCW040220K0FKED
VISHAY CRCW040240K2FKED
LINEAR TECHNOLOGY LT3992EFE
SUNCON 100CE22BS
MURATA GRM21BR61C106KE15L OPTION
SANYO 100CE22BS OPTION
AVX 06031C103KAT OPTION
AVX 12101C225KAT2A OPTION
MURATA GRM155R71C103KA01D OPTION
ON SEMICONDUCTOR MMSD701T1G OPTION
OPTION
VISHAY CRCW06030000Z0EA OPTION
TAIYO YUDEN FBMJ3216HS800 OPTION
VISHAY IHLP4040DZ-01 OPTION
SAMTEC TMM-104-02-L-S
MILL-MAX 2501-2-00-80-00-00-07-0
MILL-MAX 2308-2-00-80-00-00-07-0
SAMTEC 2SN-BK-G
dc1537af
