Pre-Installation And Application Warnings - Directed DB3 Installation Manual

Pre-installation and application warnings

Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
Important! The firmware does not control the OEM alarm. Remove the battery in the OEM remote to prevent the vehicle
Š
from arming. The vehicle's OEM alarm will no longer be functional. The installation of a hybrid system (remote starter and
alarm combo) is highly recommended to preserve vehicle security.
Key2GO is mandatory to control the immobilizer override in this firmware.
Š
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
Š
connector.
Refer to the "Vehicle connections" following the installation diagram.
Š
General notes: This section highlights important information for this specific firmware.
Tach wire is an optional connection required on some remote starters, which do not support a tach signal in D2D.
[1]
The installation of an aftermarket hood pin is ONLY required on vehicles that are NOT equipped with a factory hood pin or
[2]
not supported in Data.
The Key Release connection is only required if Pit Stop Mode is desired.
[3]
For trunk release to operate, ALL doors need to be unlocked first.
[4]
5
403.CHRYSLER12 1.24 2019 Dodge/Ram ProMaster City
©2022 VOXX•DEI LLC. All rights reserved.
Keys required for 1 Keys required for
programming operation
0
