Testing the Recorder
Outputs
Troubleshooting and Maintenance
The Recorder Test Menu enables you to test outputs to make sure
they are operating properly.You can use this menu to test any
percentage of the full scale recorder range. Use Table 2-2 to enter the
Recorder Test Menu.
Note: The Series 1 temporarily stops making measurements when
this menu is active.
Table 2-2: Moving from Main Menu to Recorder Test Menu
Press the following menu keys:
SETTINGS*
OUTPUTS
RECORDER
TEST
*The Settings Menu will prompt for a passcode (see Entering the
Passcode in Chapter 2 of the Startup Guide).
A screen similar to Figure 2-2 appears. Use the following procedure
to test recorders.
RECORDER OUTPUT TEST
Ch Recorder A
% of Scale
1 0
2 0
3 0
4 0
5 0
6 0
NOTE: Recorders SUSPENDED during test.
Recorder Test Menu
HELP TRIM
Figure 2-2: Recorder Test Menu
June 2003
To enter the:
Settings Menu
Output Settings Menu
Recorder Settings Menu
Recorder Test Menu
Recorder B
0
0
0
0
0
0
--- DONE
