Connecting Pressure
Transmitters (cont.)
Installing Optional Features

Replacing the Channel Card

1. Once the switches are set, replace the channel card.
If you intend to connect pressure inputs or other type of input devices
to the Series 1, do not replace the cover because you will need to set
switches on the channel card(s) for those inputs as well.
2. Slide the electronics unit into its enclosure and replace the screws.
Tighten the screws until they are snug. Do not over tighten.
You have completed connecting the pressure transmitter.
ON
Figure 1-11: Switch S1 on the Channel Card
S1
June 2003
1-15
