June 2003
Trimming Recorder
Outputs (cont.)
Procedure for Trimming
the Zero Value
2-6
Series 1
MOISTURE IMAGE
SERIES 2
POWER
Red+
Chart Recorder
Figure 2-4: Checking Series 1 Voltage Outputs
1. Use Table 2-3 below to enter the Recorder Test Menu. The screen
appears similar to Figure 2-5.
Table 2-3: Moving from Main Menu to Recorder Test Menu
Press the following menu keys:
SETTINGS*
OUTPUTS
RECORDER
TEST
*The Settings Menu will prompt for a passcode (see page 2-5 of the
Startup Guide).
1 2 3 YES
4 5 6 NO
7 8 9
.
- 0
Red-
DMM
To enter the:
Settings Menu
Output Settings Menu
Recorder Settings Menu
Recorder Test Menu
Troubleshooting and Maintenance
