Stainless Steel Tubing
(soft soldered to cover)
3/4-26 THD Female
(soft soldered to cover)
M2 Probe
Rubber Septum
Exhaust
Soft Solder
Metal Cover with
Teflon Washer
Liquid
Glass Bottle
Magnetic Stirrer Bar
Magnetic Stirrer
Figure A-3: Moisture Content Test Apparatus
Application of the Hygrometer (900-901D1)
A-33
