June 2003
Adding or Removing a
PCMCIA Card
Procedure for Adding or
Removing a PCMCIA
Card
2-16
To expand the memory or replace software, the Series 1 controller
board has brackets for a linear SRAM PCMCIA expansion card that
can hold up to 1 Mbyte of data. To install or remove the card, proceed
as described below.
The Series 1 is not compatible with a flash or ATA card.
Please contact GE Panametrics for a list of compatible
devices and formatting.
1. Make sure you have a record of the following data, described in
the Programming Manual on the referenced pages:
Note: This information should have been recorded on the Program
Information List in Appendix A of the Startup Guide or on a
separate sheet of paper.
•
Probe configuration (page 2-9)
•
Probe calibration data (see the Calibration Data Sheets). See page
2-12.
•
Reference values (page 2-17)
•
Recorder Outputs (page 3-3)
•
Alarm Outputs (page 3-4)
•
Data Logger (page 3-18)
Make sure you have a record of the data listed above
before you reinitialize the system.
2. Turn the power off and unplug the unit.
3. Discharge static from your body.
4. Open the enclosure by removing the screws on the front panel and
sliding the electronics unit out.
Caution!
Caution!
Troubleshooting and Maintenance
