Testing the Alarm
Relays
2-2
The Relay Test Menu enables you to either trip or reset the alarm
relays. To enter this menu use Table 2-1.
Table 2-1: Moving from Main Menu to Relay Test menu
Press the following menu keys:
SETTINGS*
OUTPUTS
ALARMS**
TEST
*The Settings Menu will prompt for a passcode (see Entering the
Passcode in Chapter 2 of the Startup Guide).
1. At the Alarm Settings Menu, press the CHANNEL menu key to
scroll to the desired channel before pressing the TEST key.
2. When you enter the Relay Test Menu, a screen similar to Figure 2-
1 appears. To trip or reset alarms, use the A
move the pointer to the desired alarm; then press the appropriate
menu keys. The word "TRIPPED" or "RESET" will appear in the
corresponding space.
ALARM RELAY STATUS
Alarm A
Reset
NOTE: Alarms SUSPENDED during test.
Relay Test Menu
HELP RESET
Figure 2-1: Relay Test Menu
3. To exit, press the DONE menu key until
message line.
If the alarms will not trip or reset, make sure the alarms are set up
correctly as described in Setting Up the Alarms in Chapter 2,
Operation, of the Programming Guide. Also, make sure the alarms
are wired correctly as described in Connecting the Alarms (page 1-6)
in Chapter 1, and that the alarm option is installed on the channel
card!
To enter the:
Settings Menu
Output Settings Menu
Alarm Settings Menu
Relay Test Menu
B menu key to
Alarm B
Tripped
A B DONE
appears on the
Main Menu
Troubleshooting and Maintenance
