LOGIQ C Series Quick Guide
Dataflow
Creates a Dataflow, ('WL-LA-DServ -- Worklist,
Local Archive, DICOM* Server, for example).
1. Name the Dataflow (select from pull-down
menu or add a new dataflow).
2. Configure the flow in the Dataflow section of the
screen. Select the service from the pull-down
menu and press Add.
Figure 20. Dataflow Preset Menu
Image Management/
Dataflow
Direction 5401576-100 Rev. 1
DICOM Status
To check the status of all DICOM jobs or redirect
DICOM jobs, press F4 to open the spooler.
Figure 21. DICOM Status Window
22
