Tech Specs - AJAX Fire Protect User Manual

Tech Specs

Smoke-sensitive element
Temperature sensitive element
Sound notification volume
Alarm threshold at the
temperature
Tamper protection
Frequency band
Compatibility
Maximum RF output power
Radio signal modulation
Radio signal range
Power supply
Battery life
Operating temperature range
Operating humidity
Overall dimensions
Weight
Photoelectric sensor
Thermocouple
85 dB at a distance of 3 m
+59°С ±2°С
Yes
868.0 – 868.6 MHz or 868.7 – 869.2 MHz depending on the
region of sale
Operates independently or with Hub, Hub Plus, Hub
2, ReX, ocBridge Plus, uartBridge
Up to 20 mW
GFSK
Up to 1,300 m (any obstacles absent)
2 × CR2 (main batteries), CR2032 (backup battery), 3 V
Up to 4 years
From 0°С to +65°С
Up to 80%
132 × 132 × 31 mm
220 g
