Table 17
Changing Your Workstation's Hardware Configuration
Installing Storage Devices

Preparing to Install Your Storage Device

This section describes information that you need to consider and procedures
that you need to perform before installing any storage device.
Configuring your Storage Device
Table 17 lists the recommended SCSI IDs for internal storage devices. If an
existing device already uses one of the suggested IDs, select an alternate ID.

Default SCSI IDs

Fast, Wide SCSI Devices
1st Hard Disk Drive
2nd Hard Disk Drive
3rd Hard Disk Drive
Single-Ended SCSI Devices
CD-ROM Drive
DDS-Format Tape Drive
NOTE: The floppy drive is not a SCSI device.
Set the jumpers and SCSI IDs according to the installation instructions that
came with your device.

Determining Your Storage Devices Position

Each storage device is restricted as to where in the storage tray it may be
installed. Before installing a storage device, use Figure 26 and Table 18 to
determine which disk tray position is correct for your device.
Figure 26 shows the storage device positions in the disk tray. Table 18 lists
what devices are supported in the different disk tray positions. The numbers
in the table's left column refer to the position numbers in the figure.
102
SCSI ID
6
5
4
SCSI ID
2
3
