Preparing to Install Your Storage Device

This section describes information that you need to consider and procedures
that you need to perform before installing any storage device.
Configuring your Storage Device
Table 17 lists the recommended SCSI IDs for internal storage devices. If an
existing device already uses one of the suggested IDs, select an alternate ID.
Table 17 Default SCSI IDs
Set the jumpers and SCSI IDs according to the installation instructions that
came with your device.

Determining Your Storage Devices Position

Each storage device is restricted as to where in the storage tray it may be
installed. Before installing a storage device, use Figure 26 and Table 18 to
determine which storage tray position is correct for your device.
Figure 26 shows the storage device positions in the storage tray. Table 18
lists what devices are supported in the different storage tray positions. The
numbers in the table's left column refer to the position numbers in the figure.
106
Fast, Wide SCSI Devices
1st Hard Disk Drive
2nd Hard Disk Drive
Single-Ended SCSI Devices
CD-ROM Drive
DDS-Format Tape Drive
NOTE: The floppy drive is not a SCSI device.
SCSI ID
6
5
SCSI ID
2
3
