Using Your CD-ROM Drive
Operating the CD-ROM Drive

Loading a CD-ROM Disc in a Vertically Mounted Drive

To load a disc in the CD-ROM drive, follow these steps:
Disc
Holder D
Disc
Holder C
Disc
Holder A
Disc
Holder B
Figure 12

Releasing the Disc Holder Retainers

1 Make sure the three disc holders are disengaged from the disc holder retainers, as
shown in Figure 12.
