Step 2. System inspection
After you click Next, the HP Toptools installation wizard will inspect the target system; examining the
system configuration, checking for the presence of required software, gathering network information and
looking for any previous versions of toptools software.
- Note -
The HP Toptools installation wizard will not allow installation to proceed under the following conditions:
•
Target OS is Win9x or pre-WinNT 4.0
•
Current user does not have local administrative rights
•
IP protocol is not installed or No IP information is available *
•
Inadequate disk space on all found drives for a bare toptools install
*The system can be properly configured for IP using DHCP, but may not have obtained IP information from the DHCP server at the
time of installation. Since IP information is required, this will halt the installation. Although it is not recommended to install toptools
onto a system using DHCP, if the HP Toptools installation wizard detects the system is configured to use DHCP, a warning dialog will
be displayed. You must install HP Toptools onto a system with a static IP address, or configure the DHCP server to reserve an IP
address for this system as the trap destination for managed devicse will be registered to this IP address.
Step 3. Required system configuration
If any of the above conditions are true, the HP Toptools installation wizard will inform you in the following
dialog box. (The HP Toptools installation wizard will use the same dialog box to inform you of
recommendations.) To allow the HP Toptools installation wizard to continue click on the Finish button.
