7

Commissioning

7.1

Starting SOPASair

7.2 Starting SOPAS ET
8027859//2022-06-22 | SICK
Subject to change without notice
Overview
SOPASair is used for operation, parameterization, and servicing purposes (e.g., diagnos‐
tics, data logger).
Prerequisites
• Computer with Ethernet connection
• Device is connected to the computer via Ethernet.
• Voltage supply is connected.
• Computer and device are located on the same network.
• Computer and device have different IP addresses.
• Access data
Rights
Read
Read and write
Approach
1. Open web browser (recommendation: Google Chrome).
2. Enter the device IP address into the address line. The standard IP address is:
192.168.0.1.
✓
The user interface is displayed.
3. To make changes, log in to the device.
Overview
SOPASair can be used to permanently save the parameters. The saved parameters can
be manually saved, imported, and exported as a project file on the computer in the
SOPAS ET configuration software.
Prerequisites
•
Computer with the SOPAS ET software installed
The most up-to-date version of the SOPAS ET software can be downloaded
from www.sick.com/SOPAS_ET. The respective system requirements for installing
SOPAS ET are also specified there.
• Ethernet connection
• SDD file (device description file)
You can install the SDD file using the device catalog in SOPAS ET. Use the wizard
in SOPAS ET to do this. The SDD file can be installed from the device or the SICK
website. To install it from the SICK website, you need an Internet connection.
• Access data
User levels
Maintenance personnel
Authorized client
Service
COMMISSIONING
Password
Can be accessed without a password
Default password: servicelevel
Password
Main
Client
Service level
O P E R A T I N G I N S T R U C T I O N S | Lector85x Flex
7
35
