  • Page 1 SuperBlade Server SBI-610P-1C2N SBI-610P-1T2N USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    SuperServer SBI-610P-1(C/T)2N User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 Eligible Enclosures ......................7 1.2 System Features ........................8 1.3 Control Panel ........................9 1.4 Front View ..........................10 1.5 Components ........................11 Chapter 2 Installation and Setup 2.1 Unpacking the System .......................13 2.2 Installing or Removing the Blade Unit ................14 Installing a Blade Unit into the Enclosure .................14 Removing a Blade Unit from the Enclosure ..............14 Removing and Replacing the Blade Cover ...............15...
  • Page 5 Contents 2.7 Installing the GPU ......................37 2.8 Installing the Operating System ..................38 2.9 Configuring RAID ........................38 2.10 Driver Installation ......................39 2.11 Installing SuperCap ......................40 Chapter 3 Management and Maintenance 3.1 Management Software ......................43 IPMI ...........................43 BMC ADMIN User Password ..................43 SuperDoctor 5........................45 ®...
  • Page 6 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 7: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview The SBI-610P-1(C/T)2N blade is a compact self-contained server that connects into a pre- cabled enclosure that provides power, cooling, management and networking functions. One enclosure can hold up to ten blades. Each blade contains one computing node. In this manual, “blade”...

  • Page 8: System Features

    Super Blade SBI-610P-1(C/T)2N User's Manual 1.2 System Features The following is an overview of the main features of the SBI-610P-1(C/T)2N blade server. System Features Motherboard B12SPE-CPU-25G-P Single Intel Xeon ICX-SP processor in Socket P+ Chipset Intel C621A Memory 16 slots for up to 4TB of DDR4 ECC RDIMM/LRDIMM/LRDIMM 3DS memory with speeds of up to 3200MHz Size Up to 256GB at 1.2V Storage Drives Two hot-swap 2.5"...

  • Page 9: Control Panel

    Chapter 1: Introduction 1.3 Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Figure 1-1. Control Panel Control Panel Features Item Feature State Description The main power switch applies or removes primary power from the Power button power supply to the server but maintains standby power.

  • Page 10: Front View

    Super Blade SBI-610P-1(C/T)2N User's Manual 1.4 Front View The illustration below shows the features on the front of the blade unit. Figure 1-2. Front View Chassis Front Features Item Features Description Control Panel Power button and status indicators Two hot-swap 2.5" drive bays for NVME, SAS, or SATA; the drive carriers display Storage Drives status lights Latch Levers...

  • Page 11: Components

    Chapter 1: Introduction 1.5 Components Figure 1-3. Components Labeled (SBI-610P-1C2N model shown)
  • Page 12 Super Blade SBI-610P-1(C/T)2N User's Manual Blade Components Item Feature Description Drives Two 2.5" storage drives Processor and heatsink Memory DIMM slots Cover Partial M.2 Slots M.2 storage card socket GPU Bay Two PCIe slots supporting up to two GPUs Mezzanine Network mezzanine add-on card Front I/O card—SAS controller for SBI-610P-1C2N, two optional M.2 slots for Bridge...

  • Page 13: Chapter 2 Installation And Setup

    Chapter 2 Installation and Setup Chapter 2 Installation and Setup This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications or part numbers. Up to ten blade modules may be installed into a blade enclosure, depending upon your enclosure and blade.

  • Page 14: Installing Or Removing The Blade Unit

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual 2.2 Installing or Removing the Blade Unit Installing a Blade Unit into the Enclosure 1. Hold the larger locking lever open and slide the blade fully into its bay. 2. As the blade is seated in the enclosure, push the larger lever into its locked position. The blade will slightly slide towards the back of the enclosure as the latches lock into position.

  • Page 15: Removing And Replacing The Blade Cover

    Chapter 2 Installation and Setup Removing and Replacing the Blade Cover The partial cover can be removed if necessary. • To remove the cover, remove the screws as illustrated below and lift it off. • To replace the cover, fit the edges of the cover into the slots on the blade, and replace the screws.

  • Page 16: Powering Up Or Down

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual 2.3 Powering Up or Down Each blade unit may be powered on and down independently from the rest of the blades in the enclosure. • Press the power button on the blade unit. • Use IPMIView or the browser based management utility to power down; requires Operator or Admin privileges on the CMM.

  • Page 17: Processor And Heatsink Installation

    • Thermal grease is pre-applied on new heatsinks. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • Graphics in this manual are for illustration only. Your components may look different.

  • Page 18: The Processor Carrier Assembly

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual The Processor Carrier Assembly The processor carrier assembly is comprised of the processor and the processor carrier. 1. Hold the processor with the land grid array (LGA, gold contacts) facing down. Locate the gold triangle at the corner of the processor and the corresponding hollowed triangle on the processor carrier as shown below.
  • Page 19 Chapter 2 Installation and Setup 3. Locate the lever on the carrier and, if necessary, press it down as shown below. Lever 4. Align the CPU keys on the processor (A & B) with those on the carrier (a & b) as shown below.

  • Page 20: The Processor Heatsink Module (Phm)

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual The Processor Heatsink Module (PHM) After creating the processor carrier assembly, mount the heatsink onto the carrier assembly to form the processor heatsink module (PHM). Note: If this is a new heatsink, the thermal grease has been pre-applied. Otherwise, apply the proper amount of thermal grease to the underside of the heatsink.

  • Page 21: Installing The Phm Into The Cpu Socket

    Chapter 2 Installation and Setup Installing the PHM into the CPU Socket 1. Remove the plastic protective cover from the CPU socket. Gently squeeze the grip tabs then pull the cover off. CPU Socket with Plastic Protective Cover Grip Tabs...
  • Page 22 SuperBlade Server SBI-610P-1(C/T)2N User's Manual 2. Locate four threaded fasteners (a, b, c, d) on the CPU socket. CPU Socket Threaded Fastener (a, b, c, d: Threaded Fasteners) CPU Socket Pin1 3. Locate four PEEK nuts (A, B, C, D) and four rotating wires (1, 2, 3, 4) on the heatsink as shown below.
  • Page 23 Chapter 2 Installation and Setup 5. Align nut A (next to the triangles and pin 1) on the heatsink with threaded fastener "a" on the CPU socket. Also align nuts B, C, D on the heatsink with threaded fasteners b, c, d on the CPU socket.

  • Page 24: Removing The Phm From The Cpu Socket

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Removing the PHM from the CPU Socket Be sure the system is shut down and all AC power cords are unplugged. 1. Use a t30-bit screwdriver to loosen the four PEEK nuts on the heatsink in the sequence of A, B, C, and D.

  • Page 25: Removing The Processor Carrier Assembly From The Phm

    Chapter 2 Installation and Setup Removing the Processor Carrier Assembly from the PHM Detach the four plastic clips (a, b, c, d) on the processor carrier assembly from the four corners of the heatsink (A, B, C, D) as shown below, and lift off the processor carrier assembly. Processor Carrier Assembly Pin 1 Pin 1...

  • Page 26: Removing The Processor From The Carrier Assembly

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Removing the Processor from the Carrier Assembly Unlock the lever from its locked position and push it upwards to disengage the processor from the carrier as shown below right. Carefully remove the processor from the carrier. Processor Carrier Assembly Lever Note: Handle the processor with care to avoid damage.

  • Page 27: Memory

    LRDIMM/3DSLRDIMM memory with speeds of up to 3200MHz. For validated memory, use Product Resources page. The following memory population sequence table was created based on guidelines provided by Intel to support Supermicro motherboards. Memory Population for the X12 UP Motherboard, 16 DIMM Slots DIMMs Memory Slots...

  • Page 28: Memory Population Guidelines

    Balance memory. Using unbalanced memory topology, such as populating two DIMMs in one channel while populating one DIMM in another channel, reduces performance. It is not recommended for Supermicro systems. • For MM, NM/FM ratio is between 1:4 and 1:16. The capacity not used for FM can be used for AD.

  • Page 29: Installing Memory

    Chapter 2 Installation and Setup Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge. •...

  • Page 30: Storage Drives

    Carriers without drives must remain in the chassis for proper airflow. For VROC configurations, refer to the VROC appendix in this manual. Note: Enterprise level storage drives are recommended for use in Supermicro systems. For information on recommended drives, visit the Supermicro website.
  • Page 31 Chapter 2 Installation and Setup Removing a Hot-Swap Drive Carrier from the Chassis 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Figure 2-4.
  • Page 32 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Installing a Drive 1. Remove the dummy drive, which comes pre-installed in the drive carrier. Pull out the two spring locking clasps and lift out the dummy drive. Post Post Locking Clasps SB414_25HDD_TRAY_ASSY_REF Figure 2-5. Removing the Dummy Drive from a Carrier 2.

  • Page 33: Hot-Swap For Nvme Drives

    Chapter 2 Installation and Setup Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Note: If you are using VROC, see the VROC appendix in this manual instead.

  • Page 34: Checking The Temperature Of An Nvme Drive

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Checking the Temperature of an NVMe Drive There are two ways to check using IPMI. Checking a Drive • IPMI > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives. • IPMI >...

  • Page 35: Solid State Drives

    Chapter 2 Installation and Setup M.2 Solid State Drives The motherboard supports one M.2 PCIe solid state drive (SSD) of length 42mm, 60mm, 80mm, or 110mm. The SBI-610P-1T2N model supports two additional M.2 NVMe SSDs of length 42mm, 80mm, or 110mm. For each length, there is a hole in the mounting platform for a plastic clasp to secure the M.2 SSD.
  • Page 36 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Installing an M.2 SSD Caution: Use industry-standard anti-static equipment, such as gloves or wrist strap, and follow precautions to avoid damage caused by ESD. 1. Insert the SSD into the socket on the motherboard or bridge board. Then push it flat against the standoff.

  • Page 37: Installing The Gpu

    Chapter 2 Installation and Setup 2.7 Installing the GPU 1. Remove the riser card assembly from the blade chassis. Note that one screw is difficult to see, as it is accessed through a hole in the bracket. (marked below as hidden) 2.

  • Page 38: Installing The Operating System

    An operating system (OS) must be installed on each blade module. Blades with Microsoft Windows OS and blades with Linux OS can operate within the same blade enclosure. Refer to the SuperMicro web site for a list of supported operating systems. Installing by using PXE Boot Preboot Execution Environment (PXE) is used to boot a computer over a network.

  • Page 39: Driver Installation

    Chapter 2 Installation and Setup 2.10 Driver Installation The Supermicro website contains drivers and utilities for your system at www.supermicro. com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard.

  • Page 40: Installing Supercap

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual 2.11 Installing SuperCap For the SBI-610P-1C2N model, an optional SuperCap kit may be installed to insure preservation of cache data in the event of a power outage. Note: SuperCap card must be installed on the AOM-BPNIO-SCE2 bridge card before the bridge card and the motherboard are installed.
  • Page 41 Chapter 2 Installation and Setup Installing SuperCap 1. Mount the SuperCap card onto the bridge board using two screws and standoffs. 2. Install the bridge board and motherboard. 3. Mount two metal standoffs and one plastic standoff onto the bridge board as shown. Plastic Standoff Figure 2-12.
  • Page 42 SuperBlade Server SBI-610P-1(C/T)2N User's Manual 4. Mount the SuperCap capacitor bracket with three screws as shown. Ensure the plastic standoff is pushed into the bracket. 5. Install SuperCap capacitor on the bracket. 6. Connect the cable to the plug on the SuperCap card. Use the cable clips on the GPU bracket.

  • Page 43: Chapter 3 Management And Maintenance

    For security, each system is assigned a unique default BMC password for the ADMIN user. This can be found on a sticker on the chassis, noted in Section 1.5, and a sticker on the motherboard. The sticker also displays the BMC MAC address. For more information: www.supermicro.com/en/support/BMC_Unique_Password. Figure 3-1 . BMC Password Label...
  • Page 44 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Service Tag Figure 3-2. Service Tag Location on Blade Module...

  • Page 45: Superdoctor ® 5

    SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 46: Motherboard Battery

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual 3.2 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 47: System Cooling

    Chapter 3 Management and Maintenance 3.3 System Cooling Installing the Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. Installing the Standard Air Shrouds • Position the air shrouds as illustrated in the figure below, sliding them over the components, and secure them with a screw.

  • Page 48: Checking The Server Air Flow

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • Do not operate the server without drive carriers in the drive bays. • Use only recommended server parts.

  • Page 49: Where To Get Replacement Components

    (www.supermicro.com/ support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 50: Power Connections

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Chapter 4 Motherboard Connections This chapter describes the jumpers, connections and LEDs on the motherboard and provides pinout definitions. Some connections might not be used in this system. 4.1 Power Connections BMC_HB_LED1 PWR1 JPFR1 JPG1 PWR2 JWD1 JTPM1...

  • Page 51: Quick Reference

    Chapter 4 Motherboard Connections Quick Reference Jumper Description Default Setting JBR1 BIOS Recovery Pins 1-2 (Enabled) JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPME1 ME Recovery Pins 1-2 (Normal) JWD1 Watch Dog Timer Pins 1-2 (Reset) Connector Description Onboard Battery...

  • Page 52: System Block Diagram

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual System Block Diagram VR13 (2+0) VR13.HC (7+1) VR13 (4+1) VR13 (4+1) VR13 (1+1) XDPE12254 XDPE12284 XDPE12254 XDPE12254 XDPE12254 VCCIO VCCP VCCSA VDDQ_ABCD VPP_ABCD VDDQ_EFGH VPP_EFGH VCC1P8 VCCANA SVID:02h SVID:00h SVID:01h SVID:00h SVID:N/A SVID:02h SVID:N/A SVID:05h SVID:06h 2 x TDA21472 7 x TDA21490...

  • Page 53: Headers And Connectors

    Chapter 4 Motherboard Connections 4.2 Headers and Connectors Main Power Connector PWR1 and PWR2 are primary power supply connectors that provide power to the motherboard via the chassis backplane. 12V GPU Power Connector JGPU1 is the EATX 12V 8-pin power connector. Proprietary Riser Power Connector JRC1 is the proprietary riser power connector with a rated 150W, two 75W CEM specification Proprietary Riser Power...
  • Page 54 The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the storage drive is not installed in the system.

  • Page 55: Jumpers

    Chapter 4 Motherboard Connections 4.3 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 56 SuperBlade Server SBI-610P-1(C/T)2N User's Manual BIOS Recovery Close pins 2-3 of jumper JBR1 for BIOS recovery. The default setting is on pins 1 and 2 for normal operation. The default setting is Normal. BIOS Recovery Jumper Settings Jumper Setting Definition Pins 1-2 Normal Pins 2-3...

  • Page 57: Led Indicators

    Chapter 4 Motherboard Connections 4.4 LED Indicators BMC Heartbeat LED BMC_HB_LED1 is the BMC heartbeat LED. When the LED is blinking green, BMC is functioning normally.

  • Page 58: Chapter 5 Uefi Bios

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Chapter 5 UEFI BIOS 5.1 Introduction This chapter describes the AMI UEFI BIOS setup utility for the B12SPE-CPU-25G-P and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published.
  • Page 59 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro B12SPE-CPU-25G-P (Motherboard model) BIOS Version Build Date (of the BIOS) CPLD (Complex Programmable Logic Device) Version: This item displays the CPLD version used in the system.

  • Page 60: Tab

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual 5.3 Tab Pages Advanced Boot Function CPU Configuration Chipset Configuration Server ME Information PCIe/PCI/PnP Configuration Super IO Configuration Serial Port Console Redirection ACPI Settings Trusted Computing Network Configuration HTTP BOOT Configuration TLS Authenticate Configuration INTEL SSDPERKX010T8-PHLJ00800K11P0I AVAGO MegaRAID <AVAGO3108 MegaRAID>...
  • Page 61 Chapter 5 UEFI BIOS Save & Exit Save Options Default Options Boot Override...

  • Page 62: Appendix A Bios Post Codes

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Appendix A BIOS POST Codes A.1 BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
  • Page 63 Appendix A BIOS POST Codes BIOS POST Messages BIOS Message Description Previous POST did not complete successfully. POST loads default values and offers to run Setup. If the failure was caused by incorrect values and Previous boot incomplete - they are not corrected, the next boot will likely fail. On systems with control of Default configuration used wait states, improper Setup settings can also terminate POST and cause this error on the next boot.
  • Page 64 SuperBlade Server SBI-610P-1(C/T)2N User's Manual BIOS POST Messages BIOS Message Description nnnn kB Extended RAM Where nnnn is the amount of RAM in kilobytes successfully tested. Passed nnnn Cache SRAM Passed Where nnnn is the amount of system cache in kilobytes successfully tested. nnnn kB Shadow RAM Passed Where nnnn is the amount of shadow RAM in kilobytes successfully tested.
  • Page 65 Appendix A BIOS POST Codes One long and two short beeps – video configuration error One repetitive long beep – no memory detected Terminal POST Errors If a terminal type of error occurs, BIOS will shut down the system. Before doing so, BIOS will write the error to port 80h, attempt to initialize video and write the error in the top left corner of the screen.
  • Page 66 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Terminal POST Errors Code Description 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Auto size DRAM Initialize POST Memory Manager Clear 512 kB base RAM 1-3-4-1 RAM failure on address line xxxx* 1-3-4-3 RAM failure on data bits xxxx* of low byte of memory bus Enable cache before system BIOS shadow Test CPU bus-clock frequency Initialize Phoenix Dispatch Manager...
  • Page 67 Appendix A BIOS POST Codes Terminal POST Errors Code Description Test keyboard Set key click if enabled Enable USB devices 2-2-3-1 Test for unexpected interrupts Initialize POST display service Display prompt “Press F2 to enter SETUP” Disable CPU cache Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1...
  • Page 68 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Terminal POST Errors Code Description Detect and install external parallel ports Initialize PC-compatible PnP ISA devices Re-initialize onboard I/O ports. Configure Motherboard Configurable Devices (optional) Initialize BIOS Data Area Enable Non-Maskable Interrupts (NMIs) Initialize Extended BIOS Data Area Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives (optional)
  • Page 69 Appendix A BIOS POST Codes Terminal POST Errors Code Description Clear Boot flag Check for errors Inform RomPilot about the end of POST. POST done - prepare to boot operating system 1 One short beep before boot Terminate QuietBoot (optional) Check password (optional) Initialize ACPI BIOS Prepare Boot...
  • Page 70 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Terminal POST Errors Code Description Initialize digitizer and display message Unknown interrupt The following are for the boot block in Flash ROM: Boot Block Flash ROM Terminal POST Errors Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O...
  • Page 71 Appendix A BIOS POST Codes Boot Block Flash ROM Terminal POST Errors Code Description Boot to Full DOS If the BIOS detects error 2C, 2E, or 30 (base 512K RAM error), it displays an additional word- bitmap (xxxx) indicating the address line or bits that failed. For example, “2C 0002” means address line 1 (bit one set) has failed.

  • Page 72: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 73 Appendix B Standardized Warning Statements for AC Systems Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 74 SuperBlade Server SBI-610P-1(C/T)2N User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 75 Appendix B Standardized Warning Statements for AC Systems Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 76 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 77 Appendix B Standardized Warning Statements for AC Systems Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 78 SuperBlade Server SBI-610P-1(C/T)2N User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 79 Appendix B Standardized Warning Statements for AC Systems ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬...
  • Page 80 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 81 Appendix B Standardized Warning Statements for AC Systems Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 82 SuperBlade Server SBI-610P-1(C/T)2N User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 83 Appendix B Standardized Warning Statements for AC Systems ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 84 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 85 Appendix B Standardized Warning Statements for AC Systems ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스...
  • Page 86 SuperBlade Server SBI-610P-1(C/T)2N User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 87 Appendix B Standardized Warning Statements for AC Systems Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 88 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 89 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 90 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 91 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 92: Appendix C Cpu-Based Raid For Nvme

    SuperBlade Server SBI-610P-1(C/T)2N User's Manual Appendix C CPU-Based RAID for NVMe Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCIe root complex. •...
  • Page 93 Appendix C CPU-Based RAID for NVMe Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm www.supermicro.com/manuals/other/AOC-VROCxxxMOD_Windows.pdf C.1 Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.
  • Page 94 SuperBlade Server SBI-610P-1(C/T)2N User's Manual C.2 Enabling NVMe RAID RAID for NVMe SSDs must be enabled through the UEFI BIOS. 1. Install the patch as described in the Restrictions and Requirements section on a previous page. 2. Reboot the server and press [DEL] key to enter BIOS. 3.
  • Page 95 Appendix C CPU-Based RAID for NVMe 5. Select the desired PStack# to Enable or Disable the corresponding Intel VMD controller Figure C-3. BIOS, Enabling VMD for Pstack0 6. Select the desired PCIe slot to Enable or Disable Intel VMD functionality according to the current hardware configuration being used.
  • Page 96 SuperBlade Server SBI-610P-1(C/T)2N User's Manual 7. Repeat steps 5-6 for each PStack# on each CPU to be enabled or disabled. In this example, we enabled CPU1 Slot1 (Figure C-5) and CPU2 Slot5 (Figure C-6) (our 4x U.2 form factor SSDs), as well as CPU1 M.2 C-1 and CPU1 M2. C-2 (our 2x M.2 form factor SSDs).
  • Page 97 Appendix C CPU-Based RAID for NVMe 8. Press [F4] to save the configuration and reboot the system and press [DEL] to enter BIOS. Note: Disabling the VMD controller without first deleting the associated existing RAID volume can lead to unexpected behavior. This action is strongly not recommended. Note: The effects of physically changing or swapping a CPU on the VMD controller enablement has not yet been thoroughly tested or documented.
  • Page 98 SuperBlade Server SBI-610P-1(C/T)2N User's Manual C.3 Status Indications An LED indicator on the drive carrier shows the RAID status of the drive. Drive Carrier Status LED Indicator Status State (red) Normal function Locating 4 Hz blink Fault Solid on Rebuilding 1 Hz Blink IBPI SFF 8489 Defined Status LED States C.4 Hot Swap Drives...

  • Page 99: Appendix D Specifications And Compliance

    Appendix D: System Specifications Appendix D Specifications and Compliance Processors Single Intel Xeon ICX-SP processor in Socket P+ Chipset Intel C621A Memory Sixteen slots for up to 4TB of DDR4 ECC RDIMM/LRDIMM/LRDIMM 3DS memory with speeds of up to 3200MHz Size Up to 256GB at 1.2V BIOS 256Mb MX25L2567 BIOS...
  • Page 100 SuperBlade Server SBI-610P-1(C/T)2N User's Manual Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 ICES-003 VCCI 32-1 AS/NZS CISPR 32 BS/EN55032 BS/EN55035 CISPR 24 BS/EN 61000-3-2 BS/EN 61000-3-3 BS/EN 61000-4-2 BS/EN 61000-4-3 BS/EN 61000-4-4...
