Related Manuals for Supermicro SuperBlade SBI-611E-1C2N
Summary of Contents for Supermicro SuperBlade SBI-611E-1C2N
- Page 1 SuperBlade Servers SBI-611E-1C2N SBI-611E-1T2N SBI-611E-5T2N USER’S MANUAL Revision 1.0...
- Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
- Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...
-
Page 4: Table Of Contents
Contents Contents Chapter 1 Introduction 1.1 Overview ..........................8 Eligible Enclosures ......................8 1.2 System Features ........................9 Front View ...........................9 Drive Carrier Indicators ....................10 Control Panel .........................11 Top view ..........................12 1.3 System Architecture ......................14 1.4 Motherboard Layout ......................17 Quick Reference .......................18 Motherboard Block Diagram .....................19 Chapter 2 Installation and Setup 2.1 Unpacking the System .......................20 2.2 Installing or Removing the Blade Unit ................21... - Page 5 Contents M.2 Solid State Drives .....................39 Hot-Swap for NVMe Drives ....................41 2.7 System Cooling ........................42 Installing the Air Shrouds ....................42 Checking the Server Air Flow ...................43 Overheating ........................43 Checking the Temperature of an NVMe Drive ..............43 2.8 Installing the GPU ......................44 2.9 Installing the Operating System ..................45 2.10 Configuring RAID ......................45 2.11 Driver Installation ......................46...
- Page 6 6.10 Reporting an Issue ......................74 Technical Support Procedures ..................74 Returning Merchandise for Service ...................74 Vendor Support Filing System ..................75 6.11 Feedback ...........................75 6.12 Contacting Supermicro ......................76 Appendix A BIOS POST Codes Appendix B Standardized Warning Statements for AC Systems Appendix C Specifications and Compliance...
- Page 7 San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.
-
Page 8: Chapter 1 Introduction
Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview The SBI-611E-1C2N/1T2N/5T2N blade is a compact self-contained server that connects into a pre-cabled enclosure that provides power, cooling, management and networking functions. One enclosure can hold up to ten blades. Each blade contains one computing node. In this manual, “blade”... -
Page 9: System Features
Chapter 1: Introduction 1.2 System Features The following views of the system display the main features. Front View Control Panel Storage Drive Storage Drive Latch Lever Service Tag Latch Lever Figure 1-1. Front View, SBI-611E-1C2N, SBI-611E-1T2N Control Panel Storage Drive Storage Drive Latch Lever Service Tag... -
Page 10: Drive Carrier Indicators
Chapter 1: Introduction Chassis Front Features Features Descriptons Control Panel Power button and status indicators Storage Drives Two hot-swap 2.5" drive bays; the drive carriers display status lights Latch Levers Levers for two latches that secure the blade in the enclosure Service/Asset Pull-out identifier (with BMC ADMIN default password... -
Page 11: Control Panel
Chapter 1: Introduction Control Panel System Fail LED KVM/UID LED Power NIC LED Power LED Figure 1-2. Control Panel Control Panel Features Feature State Description The main power switch applies or removes primary power from the power Power button supply to the server but maintains standby power. Green Power on Power LED... -
Page 12: Top View
Chapter 1: Introduction Top view M.2 Socket DIMMs Processor and Heatsink M.2 Sockets LSI SAS Controller Disk Cage Latch Levers Figure 1-3. Components Labeled (SBI-611E-1C2N model shown) - Page 13 Chapter 1: Introduction Blade Components Item Feature Description Drives Two 2.5" storage drives Processors and heatsinks Memory DIMM slots Cover Partial chassis cover Mezzanine Network mezzanine add-on card Latch Levers Levers for two latches that secure the blade in the enclosure LSI SAS Controller For SAS support Single width (double width in SBI-611E-5T2N)
-
Page 14: System Architecture
Chapter 1: Introduction 1.3 System Architecture This section shows system block diagrams. Figure 1-5. System Block Diagram, SBI-611E-1C2N... - Page 15 Chapter 1: Introduction Figure 1-6. System Block Diagram, SBI-611E-1T2N...
- Page 16 Chapter 1: Introduction Figure 1-7. System Block Diagram, SBI-611E-5T2N...
-
Page 17: Motherboard Layout
Chapter 1: Introduction 1.4 Motherboard Layout Below is a layout of the B13SEE-CPU-25G motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 3 or the Motherboard Manual. -
Page 18: Quick Reference
Chapter 1: Introduction Quick Reference Jumper Description Default Setting JBRE1 BIOS Recovery Pins 1-2 (Normal) JPG1 VGA Enable/Disable Pins 1-2 (Enable) JPME1 ME Recovery Mode Pins 1-2 (Normal) JPME2 Manufacturing Mode Pins 1-2 (Normal) JWD1 Watchdog Timer Pins 1-2 (Reset) Connector Description Onboard CMOS Battery... -
Page 19: Motherboard Block Diagram
Chapter 1: Introduction Motherboard Block Diagram SVID#0 SVID#1 DDR5-CHC DDR5-CHC 4800 MHz 4800 MHz DDR5-CHC DDR5-CHC 4800 MHz 4800 MHz DDR5-CHC DDR5-CHC 4800 MHz 4800 MHz DDR5-CHC DDR5-CHC 4800 MHz 4800 MHz PCIe 5.0 x16 PCIe 4.0 x 8 2x MCIO x8 Mezzanine 32 GT/s 16 GT/s... -
Page 20: Chapter 2 Installation And Setup
Chapter 2: Installation and Setup Chapter 2 Installation and Setup This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications or part numbers. Up to ten blade modules may be installed into a blade enclosure, depending upon your enclosure and blade. -
Page 21: Installing Or Removing The Blade Unit
Chapter 2: Installation and Setup 2.2 Installing or Removing the Blade Unit Installing a Blade Unit into the Enclosure 1. Pull the locking levers out and apart, and push the blade into its bay. Caution: Insert the blade carefully so the rear connectors are not damaged. 2. -
Page 22: Powering Up Or Down
• Thermal grease is pre-applied on new heatsinks. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • Graphics in this manual are for illustration only. Your components may look different. -
Page 23: The Processor Carrier Assembly
Chapter 2: Installation and Setup The Processor Carrier Assembly The processor carrier assembly is comprised of the processor and the processor carrier. 1. Hold the processor with the land grid array (LGA, gold contacts) facing down. Locate the gold triangle at the corner of the processor and the corresponding hollowed triangle on the processor carrier as shown below. - Page 24 Chapter 2: Installation and Setup 3. Locate the lever on the carrier and, if necessary, press it down as shown below. Lever 4. Align the CPU keys on the processor (A & B) with those on the carrier (a & b) as shown below.
-
Page 25: The Processor Heatsink Module (Phm)
Chapter 2: Installation and Setup The Processor Heatsink Module (PHM) After creating the processor carrier assembly, mount the heatsink onto the carrier assembly to form the processor heatsink module (PHM). Note: If this is a new heatsink, the thermal grease has been pre-applied. Otherwise, apply the proper amount of thermal grease to the underside of the heatsink. -
Page 26: Installing The Phm Into The Cpu Socket
Chapter 2: Installation and Setup Installing the PHM into the CPU Socket 1. Remove the plastic protective cover from the CPU socket. Gently squeeze the grip tabs then pull the cover off. CPU Socket with Plastic Protective Cover Grip Tabs... - Page 27 Chapter 2: Installation and Setup 2. Locate four threaded fasteners (a, b, c, d) on the CPU socket. CPU Socket Threaded Fastener (a, b, c, d: Threaded Fasteners) CPU Socket Pin1 3. Locate four PEEK nuts (A, B, C, D) and four rotating wires (1, 2, 3, 4) on the heatsink as shown below.
- Page 28 Chapter 2: Installation and Setup 5. Align nut A (next to the triangles and pin 1) on the heatsink with threaded fastener "a" on the CPU socket. Also align nuts B, C, D on the heatsink with threaded fasteners b, c, d on the CPU socket.
-
Page 29: Removing The Phm From The Cpu Socket
Chapter 2: Installation and Setup Removing the PHM from the CPU Socket Be sure the system is shut down and all AC power cords are unplugged. 1. Use a t30-bit screwdriver to loosen the four PEEK nuts on the heatsink in the sequence of A, B, C, and D. -
Page 30: Removing The Processor Carrier Assembly From The Phm
Chapter 2: Installation and Setup Removing the Processor Carrier Assembly from the PHM Detach the four plastic clips (a, b, c, d) on the processor carrier assembly from the four corners of the heatsink (A, B, C, D) as shown below, and lift off the processor carrier assembly. Processor Carrier Assembly Pin 1 Pin 1... -
Page 31: Removing The Processor From The Carrier Assembly
Chapter 2: Installation and Setup Removing the Processor from the Carrier Assembly Unlock the lever from its locked position and push it upwards to disengage the processor from the carrier as shown below right. Carefully remove the processor from the carrier. Processor Carrier Assembly Lever Note: Handle the processor with care to avoid damage. -
Page 32: Memory
4800 MT/s in 8 DIMM slots or 4400 MT/s in 16 DIMM slots. For validated memory, use our Product Resources page. Check the Supermicro website for possible updates to memory support. DDR5 Memory Support 4th Generation Intel Xeon Scalable Processor Speed (MT/s) Ranks Per... - Page 33 Chapter 2: Installation and Setup Use the DIMM slots listed below for memory modules. This memory population table is based on guidelines provided by Intel to support Supermicro motherboards. Memory Population for 16 DIMM Slots DIMMs Slots 1 DIMM A1 or B1 or E1 or F1...
-
Page 34: Optane Pmem Population
Chapter 2: Installation and Setup Optane PMem Population PMem 300 Series Population with 16 DIMMs DIMMs DIMMs DDR5+ Mode PMem Interleave 1LM+AD, DDR5 PMem DDR5 PMem PMem DDR5 PMem DDR5 MM+AD DDR5 DDR5 DDR5 DDR5 PMem DDR5 DDR5 1LM+AD ADx1 DDR5 DDR5 DDR5... -
Page 35: Installing Memory
Chapter 2: Installation and Setup Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge. •... -
Page 36: Storage Drives
These carriers also help promote proper airflow. Carriers without drives must remain in the chassis for proper airflow. Note: Enterprise level storage drives are recommended for use in Supermicro systems. For information on recommended drives, visit the Supermicro website. - Page 37 Chapter 2: Installation and Setup Removing a Hot-Swap Drive Carrier from the Chassis 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Figure 2-5.
- Page 38 Chapter 2: Installation and Setup Installing a Drive 1. Remove the dummy drive, which comes pre-installed in the drive carrier. Pull out the two locking clasps and lift out the dummy drive. Post Post Locking Clasps SB414_25HDD_TRAY_ASSY_REF Figure 2-6. Removing the Dummy Drive from a Carrier 2.
-
Page 39: Solid State Drives
Chapter 2: Installation and Setup M.2 Solid State Drives The motherboard supports one M.2 PCIe solid state drive (SSD) of length 80mm or 110mm. The SBI-611E-1T2N model supports two additional M.2 NVMe SSDs of length 80mm or 110mm. For each length, there is a hole in the mounting platform for a plastic clasp to secure the M.2 SSD. - Page 40 Chapter 2: Installation and Setup Installing an M.2 SSD Caution: Use industry-standard anti-static equipment, such as gloves or wrist strap, and follow precautions to avoid damage caused by ESD. 1. Insert the SSD into the socket on the motherboard or bridge board. Then push it flat against the standoff.
-
Page 41: Hot-Swap For Nvme Drives
Chapter 2: Installation and Setup Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using the BMC Dashboard. Ejecting a Drive 1. -
Page 42: System Cooling
Chapter 2: Installation and Setup 2.7 System Cooling Installing the Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. • Position the air shrouds as illustrated in the figure below, sliding them over the components. Shroud Shroud Figure 2-9. Installing the Standard Air Shrouds... -
Page 43: Checking The Server Air Flow
Chapter 2: Installation and Setup Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • Do not operate the server without drive carriers in the drive bays. • Use only recommended server parts. -
Page 44: Installing The Gpu
Chapter 2: Installation and Setup 2.8 Installing the GPU 1. Remove the riser card assembly from the blade chassis. Note that one screw is difficult to see, as it is accessed through a hole in the bracket. (marked below as hidden) 2. -
Page 45: Installing The Operating System
An operating system (OS) must be installed on each blade module. Blades with Microsoft Windows OS and blades with Linux OS can operate within the same blade enclosure. Refer to the SuperMicro web site for a list of supported operating systems. Installing by using PXE Boot Preboot Execution Environment (PXE) is used to boot a computer over a network. -
Page 46: Driver Installation
Chapter 2: Installation and Setup 2.11 Driver Installation The Supermicro website contains drivers and utilities for your system at www.supermicro. com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. -
Page 47: Installing Supercap
Chapter 2: Installation and Setup 2.12 Installing SuperCap For the SBI-611E-1C2N model, an optional SuperCap kit may be installed to insure preservation of cache data in the event of a power outage. Note: SuperCap card must be installed on the AOM bridge card before the bridge card and the motherboard are installed. - Page 48 Chapter 2: Installation and Setup Installing SuperCap 1. Mount the SuperCap card onto the bridge board using two screws and standoffs. 2. Install the bridge board and motherboard. 3. Mount two metal standoffs and one plastic standoff onto the bridge board as shown. Plastic Standoff Figure 2-13.
- Page 49 Chapter 2: Installation and Setup 4. Mount the SuperCap capacitor bracket with three screws as shown. Ensure the plastic standoff is pushed into the bracket. 5. Install SuperCap capacitor on the bracket. 6. Connect the cable to the plug on the SuperCap card. Use the cable clips on the GPU bracket.
-
Page 50: Chapter 3 Motherboard Connections
Chapter 3: Motherboard Connections Chapter 3 Motherboard Connections This chapter describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1. - Page 51 The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the storage drive is not installed in the system.
-
Page 52: Jumpers
Chapter 3: Motherboard Connections 3.2 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations. - Page 53 Chapter 3: Motherboard Connections VGA Enable/Disable Use jumper JPG1 to enable or disable the VGA port using the onboard graphics controller. The default setting is Enabled. VGA Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled Management Engine (ME) Recovery Use jumper JPME1 to select ME Firmware Recovery mode, which will limit resource allocation for essential system operation only in order to maintain normal power operation and management.
-
Page 54: Led Indicators
Chapter 3: Motherboard Connections 3.3 LED Indicators BMC Heartbeat LED LEDM1 is a BMC Heartbeat indicator. It blinks green when the BMC is working properly. -
Page 55: Chapter 4 Software
1. Create a method to access the MS Windows installation ISO file. That can be a USB flash or media drive. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive. - Page 56 Chapter 4: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 4-2.
-
Page 57: Driver Installation
The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash or media drive. -
Page 58: Superdoctor ® 5
4.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP). -
Page 59: Bmc
This can be found on a sticker on the chassis and a sticker on the motherboard. The sticker also displays the BMC MAC address. If necessary, the password can be reset using the Supermicro IPMICFG tool. Figure 4-5. BMC Password Label The sticker can be found on the pull-out service tag at the front of the chassis. -
Page 60: Chapter 5 Optional Components
The JTPM1 header is used to connect a Trusted Platform Module (TPM). A TPM is a security device that supports encryption and authentication in hard drives. It enables the motherboard to deny access if the TPM associated with the hard drive is not installed in the system. Details and installation procedures are at: http://www.supermicro.com/manuals/other/TPM.pdf. -
Page 61: Chapter 6 Troubleshooting And Support
Chapter 6 Troubleshooting and Support 6.1 Information Resources Website A great deal of information is available on the Supermicro website, supermicro.com. Figure 6-1. Supermicro Website • Specifications for servers and other hardware are available by clicking the Products option. •... -
Page 62: Bmc Interface
Security Center for recent security notices Supermicro Phone and Addresses 6.2 BMC Interface The system supports a Baseboard Management Controller (BMC) interface. It provides remote access, monitoring and management. There are several BIOS settings related to the BMC. -
Page 63: Troubleshooting Procedures
Chapter 6: Troubleshooting and Support 6.3 Troubleshooting Procedures Use the following procedures to troubleshoot your system. If you have followed all of the procedures below and still need assistance, refer to the Technical Support Procedures Returning Merchandise for Service sections in this chapter. Power down the system before changing any non hot-swap hardware components. -
Page 64: System Boot Failure
• Memory: Make sure that the memory modules are supported. Refer to the product page on our website at www.supermicro.com. Test the modules using memtest86 or a similar utility. • Storage drives: Make sure that all drives work properly. Replace if necessary. - Page 65 Chapter 6: Troubleshooting and Support • Adequate power supply: Make sure that the power supply provides adequate power to the system. Make sure that all power connectors are connected. Refer to the Supermicro website for the minimum power requirements. •...
-
Page 66: Replacing The Battery
Chapter 6: Troubleshooting and Support 6.4 Replacing the Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system. -
Page 67: Crash Dump Using The Bmc Dashboard
In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using the BMC Dashboard. The BMC manual is available at www.supermicro.com/manuals/ other/BMC_Users_Guide_X12_H12.pdf. Check Error Log 1. -
Page 68: Uefi Bios Recovery
Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. - Page 69 USB flash or media drive. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
- Page 70 Chapter 6: Troubleshooting and Support Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below. 4. When the screen as shown above displays, use the arrow keys to select the item "Proceed with flash update"...
- Page 71 Chapter 6: Troubleshooting and Support 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu. From the submenu list, select Boot Option #1 as shown below. Then, set Boot Option #1 to [UEFI AP:UEFI: Built-in EFI Shell]. Press <F4>...
- Page 72 Chapter 6: Troubleshooting and Support Note: Do not interrupt this process until the BIOS flashing is complete. 9. The screen above indicates that the BIOS update process is complete. When you see the screen above, unplug the AC power cable from the power supply, clear CMOS, and plug the AC power cable in the power supply again to power on the system.
-
Page 73: Cmos Clear
Chapter 6: Troubleshooting and Support 6.7 CMOS Clear JBT1 is used to clear CMOS, which will also clear any passwords. Instead of pins, this jumper consists of contact pads to prevent accidentally clearing the contents of CMOS. To Clear CMOS 1. -
Page 74: Where To Get Replacement Components
6.9 Where to Get Replacement Components If you need replacement parts for your system, to ensure the highest level of professional service and technical support, purchase exclusively from our Supermicro Authorized Distributors/System Integrators/Resellers. A list can be found at: http://www.supermicro.com. -
Page 75: Vendor Support Filing System
For issues related to Red Hat Enterprise Linux, since it is a subscription based OS, contact your account representative. 6.11 Feedback Supermicro values your feedback as we strive to improve our customer experience in all facets of our business. To provide feedback on our manuals, please email us at techwriterteam@... -
Page 76: Contacting Supermicro
San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) Sales-USA@supermicro.com (Sales Inquiries) Government_Sales-USA@supermicro.com (Gov. Sales Inquiries) support@supermicro.com (Technical Support) RMA@supermicro.com (RMA Support) Webmaster@supermicro.com (Webmaster) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. -
Page 77: Appendix A Bios Post Codes
Appendix A: BIOS POST Codes Appendix A BIOS POST Codes A.1 BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages. - Page 78 Appendix A: BIOS POST Codes BIOS POST Messages BIOS Message Description Previous POST did not complete successfully. POST loads default values and offers to run Setup. If the failure was caused by incorrect values and Previous boot incomplete - they are not corrected, the next boot will likely fail. On systems with control of Default configuration used wait states, improper Setup settings can also terminate POST and cause this error on the next boot.
- Page 79 Appendix A: BIOS POST Codes BIOS POST Messages BIOS Message Description nnnn kB Extended RAM Where nnnn is the amount of RAM in kilobytes successfully tested. Passed nnnn Cache SRAM Passed Where nnnn is the amount of system cache in kilobytes successfully tested. nnnn kB Shadow RAM Passed Where nnnn is the amount of shadow RAM in kilobytes successfully tested.
- Page 80 Appendix A: BIOS POST Codes One long and two short beeps – video configuration error One repetitive long beep – no memory detected Terminal POST Errors If a terminal type of error occurs, BIOS will shut down the system. Before doing so, BIOS will write the error to port 80h, attempt to initialize video and write the error in the top left corner of the screen.
- Page 81 Appendix A: BIOS POST Codes Terminal POST Errors Code Description 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Auto size DRAM Initialize POST Memory Manager Clear 512 kB base RAM 1-3-4-1 RAM failure on address line xxxx* 1-3-4-3 RAM failure on data bits xxxx* of low byte of memory bus Enable cache before system BIOS shadow Test CPU bus-clock frequency Initialize Phoenix Dispatch Manager...
- Page 82 Appendix A: BIOS POST Codes Terminal POST Errors Code Description Test keyboard Set key click if enabled Enable USB devices 2-2-3-1 Test for unexpected interrupts Initialize POST display service Display prompt “Press F2 to enter SETUP” Disable CPU cache Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1...
- Page 83 Appendix A: BIOS POST Codes Terminal POST Errors Code Description Detect and install external parallel ports Initialize PC-compatible PnP ISA devices Re-initialize onboard I/O ports. Configure Motherboard Configurable Devices (optional) Initialize BIOS Data Area Enable Non-Maskable Interrupts (NMIs) Initialize Extended BIOS Data Area Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives (optional)
- Page 84 Appendix A: BIOS POST Codes Terminal POST Errors Code Description Clear Boot flag Check for errors Inform RomPilot about the end of POST. POST done - prepare to boot operating system 1 One short beep before boot Terminate QuietBoot (optional) Check password (optional) Initialize ACPI BIOS Prepare Boot...
- Page 85 Appendix A: BIOS POST Codes Terminal POST Errors Code Description Initialize digitizer and display message Unknown interrupt The following are for the boot block in Flash ROM: Boot Block Flash ROM Terminal POST Errors Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O...
- Page 86 Appendix A: BIOS POST Codes Boot Block Flash ROM Terminal POST Errors Code Description Initialize interrupt vectors Initialize Run Time Clock Initialize video Initialize System Management Manager Output one beep Clear Huge Segment Boot to Mini DOS Boot to Full DOS If the BIOS detects error 2C, 2E, or 30 (base 512K RAM error), it displays an additional word- bitmap (xxxx) indicating the address line or bits that failed.
-
Page 87: Appendix B Standardized Warning Statements For Ac Systems
Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/... - Page 88 Appendix B: Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
- Page 89 Appendix B: Warning Statements . ٌ ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز ٍ...
- Page 90 Appendix B: Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .יש...
- Page 91 Appendix B: Warning Statements Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
- Page 92 Appendix B: Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告 システムコンポーネントの取り付けまたは取り外しのために、...
- Page 93 Appendix B: Warning Statements אזהרה מפני ניתוק חשמלי !אזהרה יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק .לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد انطاقت...
- Page 94 Appendix B: Warning Statements ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !אזהרה .צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד واملدربيه...
- Page 95 Appendix B: Warning Statements Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
- Page 96 Appendix B: Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
- Page 97 Appendix B: Warning Statements هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل اسحبذال البطارية فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
- Page 98 Appendix B: Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
- Page 99 Appendix B: Warning Statements Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
- Page 100 Appendix B: Warning Statements هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
- Page 101 Appendix B: Warning Statements תיאום חוקי החשמל הארצי !אזהרה .התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة بالكهرباء 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
- Page 102 Appendix B: Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. סילוק המוצר !אזהרה .סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה التخلص...
- Page 103 Appendix B: Warning Statements Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
- Page 104 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
- Page 105 .قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحيUL وأCSA ( ةمالع لمحت يتلاوUL/CSA) لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عمSupermicro.
- Page 106 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
-
Page 107: Appendix C Specifications And Compliance
Appendix C: System Specifications Appendix C Specifications and Compliance Processors 4th Generation Intel Xeon Scalable processor in Socket LGA4677 with up to 56 cores and a thermal design power (TDP) of up to 350W Chipset Intel PCH C741 Memory Supports up to 4TB of DDR5 ECC RDIMM/3DSLRDIMM memory with speeds of up to 4800 MT/s in 8 DIMM slots or 4400 MT/s in 16 DIMM slots and additionally supports Intel 3rd generation Optane™... - Page 108 Appendix C: System Specifications Regulatory Compliance FCC, ICES, CE, VCCI, RCM, UKCA, NRTL, CB Safety Model UL or CSA model M628-22 Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) Electromagnetic Compatibility Regulations 2016 FCC Part 15 ICES-003 VCCI-CISPR 32 AS/NZS CISPR 32 BS/EN55032 BS/EN55035 CISPR 32...
