4
Instructions on ink tank installation
are shown on the display screen. As
instructed, grab the handle on the ink tank
cover to open it.
7
Open the pouch and remove the ink tank .
• Never touch the ink holes (a)
or metal contacts (b). Touching
these parts may cause stains,
damage the ink tank , and affect
print quality.
• Avoid dropping the ink tank after
removing it from the pouch.Otherwise,
ink may leak and cause stains.
• Do not remove and shake ink tanks that
have already been installed in the printer
because ink may leak out.
10
Repeat steps 5 to 9 to install all of the ink
tanks .

Install the Printhead

1
Open Upper Cover is shown on the
display screen. As instructed, open the top
cover .
a
Instructions on printhead replacement are
shown on the display screen.
5
While pressing the stopper of the ink tank
lock lever inwards, open the ink tank lock
lever upwards.
8
Insert the ink tank into the holder facing
as shown, with the ink holes down.
a
b
• If the ink tank does not fi t in the holder,
make sure the color of the ink tank lock
lever matches the color of the ink tank , and
check the orientation of the ink tank .
11
Close the ink tank cover .
Next, install the printhead.
• When installing the printhead, do not move the carriage (a) from the position shown in the
fi gure.
If you move the carriage (a), a warning noise sounds and the printhead cannot be installed.
If you have moved the carriage (a), close the top cover. The carriage (a) moves to the position
shown in the fi gure.
3
6
Shake the ink tanks gently 1 to 2 times
before opening the pouch.
• Failure to shake ink tanks may result in
reduced print quality because ink ingredients
have settled on the bottom of the tank.
9
Close the ink tank lock lever until it clicks
into place. Make sure the ink lamp is lit in
red.
• If the ink lamp is not lit, repeat steps 5, 8,
and 9.
