Step 8
1.
Figure A: Place the two plastic bushings (90) into the top frame (9). Place cable 1 (119) on pulley
P1 (91). Mount pulley P1 (91) to the top frame (9) with one bolt set (98).
2.
Figure B: Place two plastic bushings (90) into the top frame (9). Place cable 1 (119) on pulley P2
(91). Mount the pulley P2 (91) to the top frame (9) with one bolt set (98).
3.
Figure C: Guide cable 1 (119) over pulley P3 (91) through the left side downwards and mount
the pulley P3 (91) to the back of the press arm selector (17) with one bolt set (152). Guide cable
1 (119) underneath pulley P3 (91) right over pulley P5 (91) downwards. Mount pulley P5 (91)
to the front upright frame (8) with one bolt set (152). Guide cable 1 (119) over pulley P4 (91)
coming from underneath of pulley P5 (91) through the left side downwards. Mount pulley P4
(91) to the back of the press arm selector (17) with one bolt set (152).
4.
Figure D: Place two plastic bushings (90) into the front uprigth frame (8). Mount pulley P6 (91)
to the front upright frame (8) with one bolt set (98). Guide cable 1 1 (119) over pulley P6 (91)
coming from underneath of pulley P4 (91) through the front upright frame (8).
5.
Figure E: Place cable 1 (119) on pulley P8 (91). Mount pulley P28 (91) and pulley P8 (91) to the
top frame (9) with one bolt set (111).
6.
Figure F: Place cable 1 (119) on pulley P10 (91). Mount pulley P10 (91) to the fixing bracket (10)
with a bolt set (152).
7.
Figure G: Place cable 1 (119) on pulley P11 (91). Mount pulley P11 (91) to the fixing bracket (10)
with a bolt set (152).
8.
Figure H: Mount cable 1 (119) with a big washer (148) to the selector rod (29).
9.
Figure I: Mount pulley P7 (91) to the adjustable pulley block (27) with one bolt set (152). Place
the adjustable pulley block (27) on cable 1 (119).
10. Figure J: Mount pulley P9 (91) to the adjustable pulley block (27) with one bolt set (152). Place
the adjustable pulley block (27) on cable 1 (119).
11. Tighten all bolts with the tool.
24
WS5
