Step 16
1. Mount the seat support (59) to the upright support (58) with one bolt set (98).
2. Mount the seat support (59) and the joint plate (42) to the support (B57) with two bolt sets (96).
3. Mount the right armrest (B54) and the left armrest (B55) to the seat support (59) with two bolt
sets (96).
4. Mount the seat cushion (67) to the seat support (59) with four bolt sets (117).
5. Mount the foot extension support (B64) to the foot extension pole (B62) and the foot extension
pole (B63) with two rotate bushings (61) and two bolt sets (136).
6. Mount the foot plate (B65) to the foot extension support (B64) with two bolt sets (137).
7. Tighten all bolts with the tool.
