Instructions for Installation and Care of Arctic Cat Prowler 2012 to Present
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is
best done when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at room temperature
prior to installation.
1. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.
2. Check over the parts included in the carton with the parts list shown below:
2" Adhesive Velcro Hook Strips:
"
"
"
1" Adhesive Velcro Hook Strips:
70" Para Cord
Webbing Straps with Velcro
Webbing Straps with Grommet
Snap Stud with Screw
Cab Enclosure
If any parts are damaged or missing please contact customer service at (606) 845-7439.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Full Cab Fits Poly Windshield
AC-12PROWLER-FC05
"
"
"
"
"
"
"
"
"
30 each------------3"
4 each------------6"
4 each------------8"
2 each------------20"
2 each------------19"
2 each
4 each
2 each
6 each (1 Extra)
4 panels
Advertisement
Related Manuals for FALCON RIDGE AC-12PROWLER-FC05
Summary of Contents for FALCON RIDGE AC-12PROWLER-FC05
- Page 1 Instructions for Installation and Care of Arctic Cat Prowler 2012 to Present Full Cab Fits Poly Windshield AC-12PROWLER-FC05 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
- Page 2 3. The majority of the door is held in place by double-sided Velcro strips sewn perpendicular to the edges. You need to wrap the roll cage with one of the 6” adhesive Velcro strips first and then wrap the double- sided Velcro around the adhesive strip to provide a secure hold.
- Page 3 5. Now install the 16” long 1” wide adhesive Velcro strip down the front of the fender as shown below. 6. After the Velcro is placed at the bottom of the roll cage and along the fender line attach the front of the door to place it where it needs to be.
- Page 4 8. To finish off the door attach the 20” adhesive Velcro strip down the rear portion of the door as shown below. Then attach the door to the Velcro. 9. Once the door is in place install the rear window. The top of the windshield is held in place by two 8” Velcro tabs sewn along the edges on both sides of the brake light.
- Page 5 12. Also at this point before you lace the Rear Window to the door you should wrap a 6” strip of adhesive Velcro to the roll cage a little less than halfway up the rear bar. Then wrap the double-sided strip with the strap sewn to it around the adhesive strip with the webbing strap facing the top of the vehicle.
- Page 6 15. Start in the front and take the webbing straps with the grommet holes and attach it to the middle bolt of the windshield clamps. See photos below for reference: 16. Now take the strap and run it through the buckle sewn to the corner of the top. Do not pull tight until all straps have been attached.
- Page 7 17. Once the front straps have been attached to the windshield move to the rear of the vehicle and attach the webbing straps with double-sided Velcro to the rear bar between the rear door and the rear window. First wrap the bar with the adhesive Velcro and then wrap with the double-sided as you did with the front and rear doors.
- Page 8 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
-
Page 9: Return Policy
Any returns submitted to Falcon Ridge without a return authorization number will be charged a 20% restocking fee. If ordered from one of Falcon Ridge’s many distributors, you must first call them and see what their return policy is. Once your item reaches our production facility, our customer satisfaction team will inspect your item to ensure unused, factory new condition.
