Compaq tc1000 Maintenance And Service Manual page 4

Contents
3 Illustrated Parts Catalog
3.1 Serial Number Location . . . . . . . . . . . . . . . . . . . . . . . 3-1
3.2 Tablet PC System Major Components. . . . . . . . . . . . 3-2
3.3 Miscellaneous Cable Kit Components . . . . . . . . . . . . 3-6
3.4 Miscellaneous Plastics/Hardware Kit
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
3.5 Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
3.6 Docking Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
3.7 Docking Station Components . . . . . . . . . . . . . . . . . 3-10
3.8 Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
4 Removal and Replacement Preliminaries
4.1 Tools Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
4.2 Service Considerations. . . . . . . . . . . . . . . . . . . . . . . . 4-2
4.3 Preventing Damage to Removable Drives . . . . . . . . . 4-3
4.4 Preventing Electrostatic Damage . . . . . . . . . . . . . . . . 4-4
4.5 Packaging and Transporting Precautions . . . . . . . . . . 4-4
4.6 Workstation Precautions . . . . . . . . . . . . . . . . . . . . . . 4-5
4.7 Grounding Equipment and Methods . . . . . . . . . . . . . 4-6
5 Removal and Replacement Procedures
5.1 Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
5.2 Disassembly Sequence Chart . . . . . . . . . . . . . . . . . . . 5-3
5.3 Preparing the Tablet PC for Disassembly . . . . . . . . . 5-4
5.4 Real Time Clock (RTC) Battery . . . . . . . . . . . . . . . 5-11
5.5 Display Panel Assembly . . . . . . . . . . . . . . . . . . . . . 5-12
5.6 Speaker Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
5.7 Digitizer Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-23
5.8 System Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-24
5.9 Fan and Heat Sink . . . . . . . . . . . . . . . . . . . . . . . . . . 5-31
5.10 Modem Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34
5.11 Switch Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-35
5.12 Docking Station . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37
iv
Plastic Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-2
Cables and Connectors . . . . . . . . . . . . . . . . . . . . . . . 4-2
Maintenance and Service Guide
