Item Component
12 Battery quick check lights (3)
13 Battery quick check button
14 Battery pack release latch
15 Memory expansion and mini
PCI compartment cover
retention screws (2)
16 Memory expansion and mini
PCI compartment
Maintenance and Service Guide
Table 1-8
Bottom Components (Continued)
Function
On: Each light represents a
percent of a full charge. For
example, when all three lights are
on, the battery pack is fully
charged.
Flashing: When one light is
flashing, less than 10 percent of
a full charge remains in the
battery pack.
Activates the battery quick
check lights, which display how
much charge remains in the
battery pack.
Releases the battery pack from
the battery bay.
Secure the memory and Mini PCI
compartment cover to the
tablet PC.
Contains one memory slot for a
PC133-compliant memory module.
Also holds an optional Mini PCI
board, such as a modem board or
a combination modem and
wireless board.
