Using the DS90UB934-Q1EVM Evaluation Module
The DS90UB934-Q1 is an FPD-Link III deserializer that converts a serialized camera data input to parallel
LVCMOS output. When coupled with DS90UB913A/933 serializers, the DS90UB934-Q1 receives data
from 1-Megapixel image sensors supporting 720p/800p/960p resolution at 30-Hz or 60-Hz frame rates.
There is a 2:1 mux on the input that allows two cameras to be connected, with pin or register control of
whichever camera is active. The EVM has two Rosenberger FAKRA connectors and configurable power-
over-coax (POC) voltage for connecting the camera modules (not included). There is an onboard MSP430
which functions as a USB2ANY bridge for connecting a PC. This works with the Analog LaunchPAD GUI
tool.
NOTE: The demo board is not intended for EMI testing. The demo board was designed for easy
accessibility to device pins with tap points for monitoring or applying signals, additional pads
for termination, and multiple connector options.
1
General Description
2
Quick Start Guide
3
Demo Board Connections
4
ALP Software Setup
5
Troubleshooting ALP Software
6
Equipment References
7
PCB Schematics
8
Board Layout
1
Applications Diagram
2
Interfacing to the EVM
3
Power-Over-Coax Network
4
Launching ALP
5
Initial ALP Screen
6
Follow-up Screen
7
ALP Information Tab
8
ALP Registers Tab
9
ALP Device ID Selected
10
ALP Device ID Expanded
11
ALP Scripting Tab
12
USB2ANY Setup
13
Remove Incorrect Profile
14
Add Correct Profile
.................................................................................................................
15
Finish Setup
16
ALP No Devices Error
17
Windows 7, ALP USB2ANY Driver
18
ALP in Demo Mode
19
ALP Preferences Menu
SNLU220 – December 2016
Submit Documentation Feedback
.........................................................................................................
............................................................................................................
..................................................................................................
.........................................................................................................
...........................................................................................
....................................................................................................
...........................................................................................................
................................................................................................................
........................................................................................................
......................................................................................................
.................................................................................................
...............................................................................................................
..........................................................................................................
...........................................................................................................
.......................................................................................................
.........................................................................................................
...................................................................................................
.................................................................................................
..........................................................................................................
...........................................................................................................
..................................................................................................
.........................................................................................................
.....................................................................................................
......................................................................................
........................................................................................................
....................................................................................................
Copyright © 2016, Texas Instruments Incorporated
Contents
List of Figures
Using the DS90UB934-Q1EVM Evaluation Module
User's Guide
SNLU220 – December 2016
3
4
5
8
15
20
21
27
3
4
5
9
10
10
11
11
12
13
14
15
16
16
17
18
18
19
19
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments DS90UB934-Q1EVM
Summary of Contents for Texas Instruments DS90UB934-Q1EVM
- Page 1 User's Guide SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module The DS90UB934-Q1 is an FPD-Link III deserializer that converts a serialized camera data input to parallel LVCMOS output. When coupled with DS90UB913A/933 serializers, the DS90UB934-Q1 receives data from 1-Megapixel image sensors supporting 720p/800p/960p resolution at 30-Hz or 60-Hz frame rates.
- Page 2 Control SW-DIP4 - SW1 ........................... LEDs Trademarks Windows is a registered trademark of Microsoft Corporation. All other trademarks are the property of their respective owners. Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 3 C with Fast-mode Plus up to 1 Mbps • Flexible GPIOs for camera sync and functional safety • Single 12-V power supply for EVM System Requirements The major components of the DS90UB934-Q1EVM are: • DS90UB934-Q1 • On-board POC interface •...
- Page 4 (c) Optional 3.3-V DC power supply on J29 9. For details of pin-names and pin-functions, refer to the DS90UB934-Q1 data sheet. Figure 2. Interfacing to the EVM Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 5 Alternative to main power Power-Over-Coax Interface The DS90UB934-Q1EVM offers two power-over-coax (POC) interfaces to connect cameras through a coaxial cable with FAKRA connectors. Power is delivered on the same conductor that is used to transmit video and control channel between the host and the camera. By default, 9-V power supply is applied over the coax cable.
- Page 6 ROUT10 ROUT11 HSYNC VSYNC PCLK FPD-Link III Signals Table 4. FPD-Link III Signals REFERENCE SIGNAL DESCRIPTION RIN0+ FAKRA connector RIN1+ FAKRA connector Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 7 C Interface A standalone external I C host can connect via J4 for programming purposes. Examples of external I host controllers are Texas Instruments USB2ANY and Total Phase Aardvark I C/SPI host adapter (Total Phase Part#: TP240141). C signal levels match VDDIO which can be configured through J1 to be at 1.8 V or 3.3 V when the I interface is accessed through connectors J4.
- Page 8 System Requirements Operating System: Windows 7 64-bit ® USB: USB2ANY USB2ANY Firmware Version: 2.5.2.0 USB: Aardvark I C/SPI host adapter p/n TP240141 Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 9 Make sure all the software has been installed and the hardware is powered on and connected to the PC. Execute “Analog LaunchPAD” shortcut from the start menu. The default start menu location is under All Programs > Texas Instruments > Analog LaunchPAD vx.x.x > Analog LaunchPAD to start MainGUI.exe. Figure 4. Launching ALP The application should come up in the state shown in the figure below.
- Page 10 Figure 5. Initial ALP Screen After selecting the DS90UB934, the following screen shown in Figure 6 should appear. Figure 6. Follow-up Screen Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 11 The Information tab is shown in Figure Figure 7. ALP Information Tab Registers Tab The Register tab is shown in Figure Figure 8. ALP Registers Tab SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 12 Address 0x00 is selected as shown in Figure 9. Note that the “Value:” box, now shows the hex value of that register. Figure 9. ALP Device ID Selected Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 13 “refresh” to see the new value of the selected (highlighted) register. The box toggles on every mouse click. SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 14 0x58, 0x58) #enable I2C pass-through board.WriteI2C(0x7A, 0x5D, 0x60) #set slave ID to 0x62 board.WriteI2C(0x7A, 0x65, 0x68) #set slave alias to 0x62 Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 15 USB2ANY/Aardvark Setup found under the tools menu. Figure 12. USB2ANY Setup Highlight the incorrect profile in the Defined ALP Devices list and press the remove button. SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 16 Find the correct profile under the Select a Daughter Board list, highlight the profile and press Add. Figure 14. Add Correct Profile Select Ok and the correct profile should now be loaded. Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback...
- Page 17 Troubleshooting ALP Software www.ti.com Figure 15. Finish Setup SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 18 When the ALP is operating in demo mode there is a “(Demo Mode)” indication in the lower left of the application status bar as shown below. Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright ©...
- Page 19 After demo mode is disabled, the ALP software polls the ALP hardware. The ALP software updates and have only “DS90UB96X” under the “Devices” pulldown menu. SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 20 Keysight Technologies www.keysight.com Aardvark I C/SPI Host Adapter Part Number: TP240141 www.totalphase.com/products/aardvark_i2cspi Cable References FAKRA coaxial cable: www.leoni-automotive-cables.com Rosenberger FAKRA connector: http://www.rosenberger.com/en/products/automotive/fakra.php Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 21 I2C_SDA i SDA DESERIALIZER EMI/EMC SHIELD 12pF i GND 219-4LPST 10.0k 0022112042 LABEL "REF_CLK OSS_SEL/XOUT BMI-S-201-F Copyright © 2016, Texas Instruments Incorporated SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 22 ROUT_11/CSI_CLK0_N HSYNC R184 J7_HSYNC HSYNC/GPIO4 VSYNC R185 J7_VSYNC VSYNC/GPIO5 PCLK R186 J7_PCLK PCLK/GPIO6 TSW-115-08-L-D TOP MOUNT Copyright © 2016, Texas Instruments Incorporated Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 23 VUSB VSSU AVSS1 GPIO8/ADC3 AVCC1 AVSS2 EFC0/GPIO12/CLOCK DVCC1 DVSS1 DVCC2 DVSS2 GPIO9/ADC2 2200pF MSP430F5529IPN 0.1µF 0.1µF Copyright © 2016, Texas Instruments Incorporated SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 24 @ back channel rates of >= 10 Mbps over coax. (DS90UB953) CN2_N RIN1_N RIN1_N 49.9 0.047µF 240pF Copyright © 2016, Texas Instruments Incorporated Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 25 C130 C131 i LABEL "EXP_VDD33" VDD_3V3 0.1µF 10µF i LABEL "VDD3V3" i LABEL "GND" TSW-103-07-G-S TPS767D318PWP Copyright © 2016, Texas Instruments Incorporated SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 26 BIAS i LABEL "GND" 5-146261-1 R116 TPS74801TDRCRQ1 C522 R117 C122 4.99k C123 10.0k 0.01µF 1µF 4.7µF Copyright © 2016, Texas Instruments Incorporated Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 27 Board Layout www.ti.com Board Layout Figure 20. Top Overlay Figure 21. Top Solder SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 28 Board Layout www.ti.com Figure 22. Top Layer 1 Figure 23. Layer 2 Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 29 Board Layout www.ti.com Figure 24. Layer 3 Figure 25. Layer 4 SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 30 Board Layout www.ti.com Figure 26. Layer 5 Figure 27. Bottom Layer 6 Using the DS90UB934-Q1EVM Evaluation Module SNLU220 – December 2016 Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 31 Board Layout www.ti.com Figure 28. Bottom Solder Figure 29. Bottom Overlay SNLU220 – December 2016 Using the DS90UB934-Q1EVM Evaluation Module Submit Documentation Feedback Copyright © 2016, Texas Instruments Incorporated...
- Page 32 STANDARD TERMS AND CONDITIONS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms and conditions set forth herein.
- Page 33 FCC Interference Statement for Class B EVM devices NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 34 【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの 措置を取っていただく必要がありますのでご注意ください。 1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用 いただく。 2. 実験局の免許を取得後ご使用いただく。 3. 技術基準適合証明を取得後ご使用いただく。 なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。 上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ ンスツルメンツ株式会社 東京都新宿区西新宿６丁目２４番１号 西新宿三井ビル 3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page 電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/ /www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page SPACER EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
- Page 35 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2016, Texas Instruments Incorporated...
- Page 36 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, enhancements, improvements and other changes to its semiconductor products and services per JESD46, latest issue, and to discontinue any product or service per JESD48, latest issue.
- Page 37 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments DS90UB934-Q1EVM...
