Video; Camera - Direct IP Idis DC-D4236WRX Operation Manual

Video

Configure Camera, Streaming, Webcasting, MAT,
Privacy Masking and OSD options.

Camera

Image Sensor
Configure Image Sensor settings.
• Frame Rate: Set the frame rate of image sensor.
Streaming settings are reset when changing the
frame rate.
Streaming settings are reset when changing the
frame rate.
• Mirroring: Select Horizontal Reverse or Vertical
Reverse to flip the image horizontally or vertically.
• Pivot: Select a direction to rotate images 90 degrees
clockwise or counterclockwise. If vertical resolution
is less than 320, this function is not supported. If you
enable this function, you can monitor more efficiently
long and narrow space such as hallways, corridors,
etc. If both Mirroring and Pivot functions are enabled,
Mirroring functions first, then Pivot.
With Pivot used, 3840x2160 resolution and
maximum IPS using 30ips are limited.
Part 1 - Remote Setup
17
