Video; Camera - Direct IP IDIS DC-D4517RXP Operation Manual

Part 1 - Remote Setup

Video

Configure Camera, Streaming, MAT, Privacy Masking
and OSD options.
16

Camera

Image Sensor
Configure Image Sensor settings.
• Mode: Choose resolution(16:9 for 4M and 4:3 for 5M).
When changing sensor mode, some settings will be
reset to default.
• Frame Rate: Set the frame rate of image sesor.
Streaming settings are reset when changing the
frame rate.
Streaming settings are reset when changing the
frame rate.
• Mirroring: Select Horizontal Reverse or Vertical
Reverse to flip the image horizontally or vertically.
• Pivot: Select a direction to rotate images 90 degrees
clockwise or counterclockwise. If vertical resolution
is less than 320, this function is not supported. If you
enable this function, you can monitor more efficiently
long and narrow space such as hallways, corridors,
etc. If both Mirroring and Pivot functions are enabled,
Mirroring functions first, then Pivot.
With Pivot used, 3840x2160 resolution and maximum
IPS using 30ips are limited.
• Defog: Disables or enables the Defog feature. When it
is enabled, image with a fog is adjusted.
• 3DNR: Set the strength of 3DNR (3D Noise Reduction).
A higher 3DNR value reduces background noise in a
low-light environment, but it may cause afterimage
(lag) of moving objects.
