Camera

Image Sensor
Configure Image Sensor settings.
• Frame Rate: Set the frame rate of image sesor.
Streaming settings are reset when changing the
frame rate.
Streaming settings are reset when changing the
frame rate.
• Mirroring: Select Horizontal Reverse or Vertical
Reverse to flip the image horizontally or vertically.
• Pivot: Select a direction to rotate images 90 degrees
clockwise or counterclockwise. If vertical resolution
is less than 320, this function is not supported. If you
enable this function, you can monitor more efficiently
long and narrow space such as hallways, corridors,
etc. If both Mirroring and Pivot functions are enabled,
Mirroring functions first, then Pivot.
With Pivot used, 3840x2160 resolution and
maximum IPS using 30ips are limited.
White Balance
Configure White Balance settings.Preset: Use
preconfigured white balance settings.
• Preset: Use preconfigured white balance settings.
- Auto: Allow the system to adjust the white
balance automatically. The system will assess the
lighting conditions and adjust the white balance
automatically.
- Hold: Hold the current white balance.
- INCANDESCENT - FLUORESCENT COLD: Select
a lighting type to apply the appropriate white
balance.
If the Preset is Hold and the WDR mode is changed,
a reset is required.
• Manual: Adjust the white balance manually. Adjust
Red and Blue gain values. Greater the value, greater
the intensity of the corresponding color.
If the white balance does not work properly under the
following specific conditions, select Manual or Hold.
- When the surrounding environment of the object is
out of the color temperature correction range
- When the surrounding environment of the object is
dark
- The camera is pointed directly at the fluorescent lamp
or installed in a place where the lighting change is
severe.
