4
Machine description – quick overview
4.1
Front view
Item Symbol
1
2
3
4
5
6
099-002128-EW501
26.01.2022
Machine description – quick overview
Description
0
Carrying strap > see 5.1.4.1 chapter
Machine control > see 4.3 chapter
Protective cap
Connection socket, "+" welding current
•
MMA: Electrode holder or workpiece lead connection
•
TIG: Connection for workpiece lead
Cooling air outlet
Connection socket, "-" welding current
•
MMA: Connection of electrode holder or workpiece lead
•
TIG: Connection of TIG welding torch
Figure 4-1
Front view
15
