quadient IS-330 Installation Manual page 5

4. Install Ink Cartridge
Remove the Ink Cartridge from the box and then remove the
blue tabs that are covering the print heads.
Ensuring that the power is not connected, open the top cover of
the machine. The carriage will be in the correct position to install
the cartridge.
Place the cartridge with the print heads facing down into the
carriage as shown below. When the cartridge is resting in the
carriage, click the cartridge forward into the locked position as
shown below. If the cartridge does not click in correctly start the
process again.
The Meter (PSD) and the Ink Cartridge are now installed
correctly.
Close all covers and move on to the next step.
